92 ACS550 User’s Manual
Parameters
Group 33: INFORMATION
3301
FIRMWARE 0000…FFFF hex 1 Firmware version
3302
LOADING PACKAGE 0000…FFFF hex 1 0
3303
TEST DATE yy.ww 1 0
3304
DRIVE RATING ---
3305
PARAMETER TABLE 0000…FFFF hex 1 Par. table version
Group 34: PANEL DISPLAY
3401
SIGNAL1 PARAM 100 = NOT SELECTED, 101…159 1 103 (parameter 0103
OUTPUT FREQ)
3402
SIGNAL1 MIN -1-
3403
SIGNAL1 MAX -1-
3404
OUTPUT1 DSP FORM 0…9 1 9 (DIRECT)
3405
OUTPUT1 UNIT 0…127 1 -
3406
OUTPUT1 MIN -1-
3407
OUTPUT1 MAX -1-
3408
SIGNAL2 PARAM 100 = NOT SELECTED, 101…159 1 104 (parameter 0104
CURRENT)
3409
SIGNAL2 MIN -1-
3410
SIGNAL2 MAX -1-
3411
OUTPUT2 DSP FORM 0…9 1 9 (DIRECT)
3412
OUTPUT2 UNIT 0…127 1 -
3413
OUTPUT2 MIN -1-
3414
OUTPUT2 MAX -1-
3415
SIGNAL3 PARAM 100 = NOT SELECTED, 101…159 1 105 (parameter 0105
TORQUE)
3416
SIGNAL3 MIN -1-
3417
SIGNAL3 MAX -1-
3418
OUTPUT3 DSP FORM 0…9 1 9 (DIRECT)
3419
OUTPUT3 UNIT 0…127 1 -
3420
OUTPUT3 MIN -1-
3421
OUTPUT3 MAX -1-
Group 35: MOTOR TEMP MEAS
3501
SENSOR TYPE 0…6 1 0 (NONE)
3502
INPUT SELECTION 1…8 1 1 (AI1)
3503
ALARM LIMIT Par. 3501 = 1…3: -10…200 °C
Par. 3501 = 4: 0…5000 ohm
Par. 3501 = 5…6: 0…1
1 110 °C / 1500 ohm / 0
3504
FAULT LIMIT Par. 3501 = 1…3: -10…200 °C
Par. 3501 = 4: 0…5000 ohm
Par. 3501 = 5…6: 0…1
1 130 °C / 4000 ohm / 0
Group 36: TIMED FUNCTIONS
3601
TIMERS ENABLE -6…7 1 0 (NOT SEL)
3602
START TIME 1 00:00:00…23:59:58 2 s 00:00:00
3603
STOP TIME 1 00:00:00…23:59:58 2 s 00:00:00
3604
START DAY 1 1…7 1 1 (MONDAY)
3605
STOP DAY 1 1…7 1 1 (MONDAY)
3606
START TIME 2 00:00:00…23:59:58 2 s 00:00:00
Code Name Range Resolution Default User S
