ACS550 User’s Manual 93
Parameters
3607 STOP TIME 2 00:00:00…23:59:58 2 s 00:00:00
3608
START DAY 2 1…7 1 1 (MONDAY)
3609
STOP DAY 2 1…7 1 1 (MONDAY)
3610
START TIME 3 00:00:00…23:59:58 2 s 00:00:00
3611
STOP TIME 3 00:00:00…23:59:58 2 s 00:00:00
3612
START DAY 3 1…7 1 1 (MONDAY)
3613
STOP DAY 3 1…7 1 1 (MONDAY)
3614
START TIME 4 00:00:00…23:59:58 2 s 00:00:00
3615
STOP TIME 4 00:00:00…23:59:58 2 s 00:00:00
3616
START DAY 4 1…7 1 1 (MONDAY)
3617
STOP DAY 4 1…7 1 1 (MONDAY)
3622
BOOSTER SEL -6…6 1 0 (NOT SEL)
3623
BOOSTER TIME 00:00:00…23:59:58 2 s 00:00:00
3626
…
3629
TIMED FUNC 1…4 SRC 0…31 1 0 (NOT SEL)
Group 37: USER LOAD CURVE
3701
USER LOAD C MODE 0…3 1 0 (NOT SEL)
3702
USER LOAD C FUNC 1=FAULT, 2 = ALARM 11 (FAULT)
3703
USER LOAD C TIME 10…400 s 1 s 20 s
3704
LOAD FREQ 1 0…500 Hz 1 Hz 5 Hz
3705
LOAD TORQ LOW 1 0…600% 1% 10%
3706
LOAD TORQ HIGH 1 0…600% 1% 300%
3707
LOAD FREQ 2 0…500Hz 1Hz 25Hz
3708
LOAD TORQ LOW 2 0…600% 1% 15%
3709
LOAD TORQ HIGH 2 0…600% 1% 300%
3710
LOAD FREQ 3 0…500Hz 1Hz 43Hz
3711
LOAD TORQ LOW 3 0…600% 1% 25%
3712
LOAD TORQ HIGH 3 0…600% 1% 300%
3713
LOAD FREQ 4 0…500Hz 1Hz 50Hz
3714
LOAD TORQ LOW 4 0…600% 1% 30%
3715
LOAD TORQ HIGH 4 0…600% 1% 300%
3716
LOAD FREQ 5 0…500 Hz 1 Hz 500 Hz
3717
LOAD TORQ LOW 5 0…600% 1% 30%
3718
LOAD TORQ HIGH 5 0…600% 1% 300%
Group 40: PROCESS PID SET 1
4001
GAIN 0.1…100.0 0.1 1.0
4002
INTEGRATION TIME 0.0 = NOT SEL, 0.1…3600.0 s 0.1 s 60.0 s
4003
DERIVATION TIME 0.0…10.0 s 0.1 s 0.0 s
4004
PID DERIV FILTER 0.0…10.0 s 0.1 s 1.0 s
4005
ERROR VALUE INV 0 = NO, 1 = YES 10 (NO)
4006
UNITS 0…127 1 4 (%)
4007
UNIT SCALE 0…4 1 1
4008 0%
VALUE Unit and scale defined by par. 4006 and
4007
-0.0%
Code Name Range Resolution Default User S
