94 ACS550 User’s Manual
Parameters
4009 100% VALUE Unit and scale defined by par. 4006 and
4007
- 100.0%
4010
SET POINT SEL 0…2, 8…17, 19…20 1 1 (AI1) !
4011
INTERNAL SETPNT Unit and scale defined by par. 4006 and
4007
- 40.0%
4012
SETPOINT MIN -500.0…500.0% 0.1% 0.0%
4013
SETPOINT MAX -500.0…500.0% 0.1% 100.0%
4014
FBK SEL 1…13 1 1 (ACT1)
4015
FBK MULTIPLIER 0.000 = NOT SEL, -32.768…32.767 0.001 0.000 (NOT SEL)
4016
ACT1 INPUT 1…7 1 2 (AI2) !
4017
ACT2 INPUT 1…7 1 2 (AI2) !
4018
ACT1 MINIMUM -1000…1000% 1% 0%
4019
ACT1 MAXIMUM -1000…1000% 1% 100%
4020
ACT2 MINIMUM -1000…1000% 1% 0%
4021
ACT2 MAXIMUM -1000…1000% 1% 100%
4022
SLEEP SELECTION -6…7 1 0 (NOT SEL)
4023
PID SLEEP LEVEL 0…30000 rpm / 0.0…500.0 Hz 1 rpm / 0.1 Hz 0 rpm / 0.0 Hz
4024
PID SLEEP DELAY 0.0…3600.0 s 0.1 s 60.0 s
4025
WAKE-UP DEV Unit and scale defined by par. 4006 and
4007
- 0.0%
4026
WAKE-UP DELAY 0.00…60.00 s 0.01 s 0.50 s
4027
PID 1 PARAM sET -6…14 1 0 (SET 1)
Group 41: PROCESS PID SET 2
4101
GAIN 0.1…100.0 0.1 1.0
4102
INTEGRATION TIME 0.0 = NOT SEL, 0.1…3600.0 s 0.1 s 60.0 s
4103
DERIVATION TIME 0.0…10.0 s 0.1 s 0.0 s
4104
PID DERIV FILTER 0.0…10.0 s 0.1 s 1.0 s
4105
ERROR VALUE INV 0 = NO, 1 = YES 10 (NO)
4106
UNITS 0…127 1 4 (%)
4107
UNIT SCALE 0…4 1 1
4108 0%
VALUE Unit and scale defined by par. 4106 and
4107
- 0.0%
4109 100%
VALUE Unit and scale defined by par. 4106 and
4107
- 100.0%
4110
SET POINT SEL 0…2, 8…17, 19…20 1 1 (AI1) !
4111
INTERNAL SETPNT Unit and scale defined by par. 4106 and
4107
- 40.0%
4112
SETPOINT MIN -500.0…500.0% 0.1% 0.0%
4113
SETPOINT MAX -500.0…500.0% 0.1% 100.0%
4114
FBK SEL 1…13 1 1 (ACT1)
4115
FBK MULTIPLIER 0.000 = NOT SEL, -32.768…32.767 0.001 0.000 (NOT SEL)
4116
ACT1 INPUT 1…7 1 2 (AI2) !
4117
ACT2 INPUT 1…7 1 2 (AI2) !
4118
ACT1 MINIMUM -1000…1000% 1% 0%
4119
ACT1 MAXIMUM -1000…1000% 1% 100%
4120
ACT2 MINIMUM -1000…1000% 1% 0%
4121
ACT2 MAXIMUM -1000…1000% 1% 100%
Code Name Range Resolution Default User S
