Parameters
4122 SLEEP SELECTION -6…7 1 0 (NOT SEL)
4123
PID SLEEP LEVEL 0…30000 rpm / 0.0…500.0 Hz 1 rpm / 0.1 Hz 0 rpm / 0.0 Hz
4124
PID SLEEP DELAY 0.0…3600.0 s 0.1 s 60.0 s
4125
WAKE-UP DEV Unit and scale defined by par. 4106 and
4107
-0.0%
4126
WAKE-UP DELAY 0.00…60.00 s 0.01 s 0.50 s
Group 42: EXT / TRIM PID
4201
GAIN 0.1…100.0 0.1 1.0
4202
INTEGRATION TIME 0.0 = NOT SEL, 0.1…3600.0 s 0.1 s 60 s
4203
DERIVATION TIME 0.0…10.0 s 0.1 s 0.0 s
4204
PID DERIV FILTER 0.0…10.0 s 0.1 s 1.0 s
4205
ERROR VALUE INV 0 = NO, 1 = YES 10 (NO)
4206
UNITS 0…127 1 4 (%)
4207
UNIT SCALE 0…4 1 1
4208 0%
VALUE Unit and scale defined by par. 4206 and
4207
-0.0%
4209 100%
VALUE Unit and scale defined by par. 4206 and
4207
- 100.0%
4210
SET POINT SEL 0…2, 8…17, 19…20 1 1 (AI1) !
4211
INTERNAL SETPNT Unit and scale defined by par. 4206 and
4207
- 40.0%
4212
SETPOINT MIN -500.0…500.0% 0.1% 0.0%
4213
SETPOINT MAX -500.0…500.0% 0.1% 100.0%
4214
FBK SEL 1…13 1 1 (ACT1)
4215
FBK MULTIPLIER 0.000 = NOT SEL, -32.768…32.767 0.001 0.000 (NOT SEL)
4216
ACT1 INPUT 1…7 1 2 (AI2) !
4217
ACT2 INPUT 1…7 1 2 (AI2) !
4218
ACT1 MINIMUM -1000…1000% 1% 0%
4219
ACT1 MAXIMUM -1000…1000% 1% 100%
4220
ACT2 MINIMUM -1000…1000% 1% 0%
4221
ACT2 MAXIMUM -1000…1000% 1% 100%
4228
ACTIVATE -6…12 1 0 (NOT SEL)
4229
OFFSET 0.0…100.0% 0.1% 0.0%
4230
TRIM MODE 0=NOT SEL, 1 = PROPORTIONAL,
3=
DIRECT
10 (NOT SEL)
4231
TRIM SCALE -100.0…100.0% 0.1% 0.0%
4232
CORRECTION SRC 1=PID2REF, 2 = PID2OUTPUT 11 (PID2REF)
Group 50: ENCODER
5001
PULSE NR 50…16384 1 1024 !
5002
ENCODER ENABLE 0=DISABLE, 1 = ENABLE 10 (DISABLE) !
5003
ENCODER FAULT 1=FAULT, 2 = ALARM 11 (FAULT) !
5010
Z PLS ENABLE 0=DISABLE, 1 = ENABLE 10 (DISABLE) !
5011
POSITION RESET 0=DISABLE, 1 = ENABLE 10 (DISABLE)
Group 51: EXT COMM MODULE
5101
FBA TYPE --0 (NOT DEFINED)
5102 …
5126
FB PAR 2…26 0…65535 1 0
