96 ACS550 User’s Manual
Parameters
5127 FBA PAR REFRESH 0 = DONE, 1 = REFRESH 10 (DONE) !
5128
FILE CPI FW REV 0…0xFFFF (hex) 1 0
5129
FILE CONFIG ID 0…0xFFFF (hex) 1 0
5130
FILE CONFIG REV 0…0xFFFF (hex) 1 0
5131
FBA STATUS 0…6 1 0 (IDLE)
5132
FBA CPI FW REV 0…0xFFFF (hex) 1 0
5133
FBA APPL FW REV 0…0xFFFF (hex) 1 0
Group 52: PANEL COMM
5201
STATION ID 1…247 1 1
5202
BAUD RATE 9.6, 19.2, 38.4, 57.6, 115.2 kbits/s - 9.6 kbits/s
5203
PARITY 0 = 8 NONE 1, 1 = 8 NONE 2,
2=8
EVEN 1, 3 = 8 ODD 1
10 (8
NONE 1)
5204
OK MESSAGES 0…65535 1 -
5205
PARITY ERRORS 0…65535 1 -
5206
FRAME ERRORS 0…65535 1 -
5207
BUFFER OVERRUNS 0…65535 1 -
5208
CRC ERRORS 0…65535 1 -
Group 53: EFB PROTOCOL
5301
EFB PROTOCOL ID 0…0xFFFF 1 0
5302
EFB STATION ID 0…65535 1 1 !
5303
EFB BAUD RATE 1.2, 2.4, 4.8, 9.6, 19.2, 38.4, 57.6, 76.8
kbits/s
- 9.6 kbits/s
5304
EFB PARITY 0 = 8 NONE 1, 1 = 8 NONE 2,
2=8
EVEN 1, 3 = 8 ODD 1
0 (8
NONE 1)
5305
EFB CTRL PROFILE 0 = ABB DRV LIM, 1 = DCU PROFILE,
2 =
ABB DRV FULL
10 (ABB DRV LIM)
5306
EFB OK MESSAGES 0…65535 1 0
5307
EFB CRC ERRORS 0…65535 1 0
5308
EFB UART ERRORS 0…65535 1 0
5309
EFB STATUS 0…7 1 0 (IDLE)
5310
EFB PAR 10 0…65535 1 0 (NOT SEL)
5311
EFB PAR 11 0…65535 1 0 (NOT SEL)
5312
EFB PAR 12 0…65535 1 0 (NOT SEL)
5313
EFB PAR 13 0…65535 1 0 (NOT SEL)
5314
EFB PAR 14 0…65535 1 0 (NOT SEL)
5315
EFB PAR 15 0…65535 1 0 (NOT SEL)
5316
EFB PAR 16 0…65535 1 0 (NOT SEL)
5317
EFB PAR 17 0…65535 1 0 (NOT SEL)
5318
EFB PAR 18 0…65535 1 0
5319
EFB PAR 19 0…0xFFFF (hex) 1 0
5320
EFB PAR 20 0…0xFFFF (hex) 1 0
Group 81: PFC CONTROL
8103
REFERENCE STEP 1 0.0…100.0% 0.1% 0.0%
8104
REFERENCE STEP 2 0.0…100.0% 0.1% 0.0%
8105
REFERENCE STEP 3 0.0…100.0% 0.1% 0.0%
Code Name Range Resolution Default User S
