ACS800-104 ordering information
107
PPCS branching units for n×R8i inverter units
Inverter units consisting of parallel-connected frame R8i inverter modules require
PPCS branching units for distribution of control signals to the modules. One
branching unit can control up to four inverter modules.
There are two types available – the NPBU-42C is the basic unit; the APBU-44C also
incorporates a datalogger and supports redundancy, enabling, in case of removal of
one inverter module, continued operation using the remaining modules.
Output (du/dt) filters for frame R2i to R7i inverter modules
For information on the usage of output (du/dt) filters, see the document ACS800
MultiDrive; Planning the Electrical Installation (3AFE 64783742, English).
Other options
See the ACS800 Product Reference (3AFE 64813340 [English]) for generic
equipment for the ACS800 product family such as control panels, I/O options,
application programs and PC tools.
PPCS branching unit (Multiples of frame R8i)
Inverter unit type
ACS800-104…
Quantity Contents of 1 kit Order code
0770-3
1030-3
0910-5
1210-5
0870-7
1160-7
1
1 pc. APBU-44C branching unit & datalogger
2 pcs. 2000 mm fibre optic cables
2 pcs. 3000 mm fibre optic cables
*68242355
1
1 pc. NPBU-42C branching unit
2 pcs. 2000 mm fibre optic cables
2 pcs. 3000 mm fibre optic cables
64349091
1540-3
2050-3
1820-5
2430-5
1740-7
2320-7
1
1 pc. APBU-44C branching unit & datalogger
4 pcs. 3000 mm fibre optic cables
4 pcs. 5000 mm fibre optic cables
*68242371
1
1 pcs. NPBU-42C branching unit
4 pcs. 3000 mm fibre optic cables
4 pcs. 5000 mm fibre optic cables
64349139
*Check availability with ABB
Output (du/dt) filters for inverter modules
Module type
ACS800-104-…
Qty Type
Order
code
I
RMS
(A)
L
(µH)
Power loss
(W)
Cable size
(mm
2
)
Connection
size
0003-3
0004-3
0005-3
0006-3
0009-3
0011-3
0004-5
0005-5
0006-5
0009-5
0011-5
0016-5
0011-7
1 NOCH0016-60 58982784 15 150 110 0.2 … 10 M5
0016-3
0020-3
0020-5 0016-7
0020-7
0025-7
1 NOCH0030-60 58982792 28 140 167 0.5 … 16 M5
0025-3
0030-3
0040-3
0050-3
0025-5
0030-5
0040-5
0050-5
0060-5
0030-7
0040-7
0050-7
0060-7
0070-7
1 NOCH0070-60 58982806 65 115 210 10 … 35 M6
0060-3
0100-3
0120-3
0070-5
0100-5
0120-5
0140-5
0100-7
0120-7
1 NOCH0120-60 58982814 105 92 80 – M8
