ABB ACS800-104

ACS800-104 ordering information
95
Frame size R8i and multiples
Multiple R8i inverter modules can be connected in parallel to produce higher output
powers. The table below shows the quantity and order code of inverter modules
required for each inverter unit.
Option key:
+C126: Speed-controlled cooling fan supplied from the DC bus
+E205: du/dt filtering (required for 690 V modules, and parallel-connected modules)
+Q950: Prevention of unexpected start (factory-installed in parallel-connected
modules) (for more information, see the document ACS800 MultiDrive; Planning the
Electrical Installation [3AFE 64783742, English]).
Inverter modules (R8i and multiples)
Inverter unit
type
Order code
Consists of
modules of type…
ACS800-104… Qty
no
options
+C126 +E205 +Q950
+C126
+E205
+C126
+Q950
+E205
+Q950
+C126
+E205
+Q950
Qty ACS800-104-…
U
N
= 400 V
0170-3 1 68262194 68260906 68262330 68262283 68260949 68260922 68262445 68260965 1 0170-3
0210-3 1 68262208 68260914 68262356 68262291 68260957 68260931 68262526 68260973 1 0210-3
0260-3 1 68262224 68259231 68262364 68262305 68259746 68259762 68262551 68259754 1 0260-3
0320-3 1 68262232 64766058 68262411 68262313 64766121 64766139 68262577 64766031 1 0320-3
0390-3 1 64694383 64793969 64694367 64694375 64793985 64794001 64694332 64793993 1 0390-3
0510-3 1 64694324 64794019 64694294 64694308 64792580 64794051 64694286 64792598 1 0510-3
0770-3 1 – – – – – – 68259410 68259436 2 0390-3
1030-3 1 – – – – – – 68259461 68259487 2 0510-3
1540-3 1 – – – – – – 68259941 68259975 3 0510-3
2050-3 1 – – – – – – 68260027 68260051 4 0510-3
U
N
= 500 V
0210-5 1 68263531 68260981 68263689 68263611 68261023 68261007 68263751 68261040 1 0210-5
0260-5 1 68263565 68260990 68263697 68263620 68261031 68261015 68263760 68261066 1 0260-5
0320-5 1 68263581 68259258 68263719 68263638 68259703 68259738 68263816 68259720 1 0320-5
0400-5 1 68263590 64766252 68263727 68263646 64766244 64766236 68263824 64766201 1 0400-5
0460-5 1 64694197 64794124 64650289 64694189 64794159 64794183 64650297 64794167 1 0460-5
0610-5 1 64694162 64794191 64650301 64694154 64794205 64794221 64650319 64794213 1 0610-5
0910-5 1 – – – – – – 68260116 68260132 2 0460-5
1210-5 1 – – – – – – 68260574 68260591 2 0610-5
1820-5 1 – – – – – – 68260612 68260647 3 0610-5
2430-5 1 – – – – – – 68260655 68260671 4 0610-5
U
N
= 690 V
0210-7 1 – – 68263841 – 68261074 – 68263921 68261091 1 0210-7
0260-7 1 – – 68263859 – 68259665 – 68263930 68259681 1 0260-7
0320-7 1 – – 68263875 – 68261082 – 68263956 68261104 1 0320-7
0400-7 1 – – 68263883 – 64766406 – 68263972 64766309 1 0400-7
0440-7 1 – – 64650327 – 64793918 – 64650335 64793926 1 0440-7
0580-7 1 – – 64650343 – 64792571 – 64650351 64794086 1 0580-7
0870-7 1 – – – – – – 68260728 68261155 2 0440-7
1160-7 1 – – – – – – 68261163 68261198 2 0580-7
1740-7 1 – – – – – – 68261201 68261210 3 0580-7
2320-7 1 – – – – – – 68261228 68261236 4 0580-7
