ABB ACS800-104

Technical data
119
Auxiliary power consumptions
Circuit boards
Cooling fans
Type
U
n
V DC
U
n
V AC
f
Hz
I
n
A
I
max
A
AGPS-11C
– 230 50 0.1 –
– 115 60 0.2 –
AGPS-21C –
230 50 0.3 –
115 60 0 .6 –
APBU-44 24 – – 0.2 –
ASFC-21C
– 230 50 0.04 –
– 115 60 0.08 –
NCHM-21 – 230 50 1.0 2.0
NCHM-22 – 115 60 2.0 4.0
NGPS-01
– 230 50/60 0.16 6.0 (1/2 cycle)
– 115 60 0.32 6.0 (1/2 cycle)
NPBU-42 24 – – 0.2 0.235
RDCU-02 24 – – 0.25 1.2
Frame
size
Type
U
n
V AC
f
Hz
I
n
A
I
start
A
R7i
G2E140-P151-09 230
50 0.7 1.4
60 0.9 1.8
G2E140-AI32-ABB 115 60 1.8 3.6
R8i D2D160-BE02-11
400 50 1.3
320 60 1.3
