ABB ACS800-104

Technical data
112
Dimensions, noise, DC capacitance
Inverter module/unit
type
Frame
size
Height Width Depth Weight
Noise
level
DC
capacitance
mm (in.) mm (in.) mm (in.) kg (lbs) dBA µF
U
N
= 400 V
ACS800-104-0003-3 R2i 401 (15.79) 165 (6.50) *193 (7.60) 9 (20) 62 350
ACS800-104-0004-3 R2i 401 (15.79) 165 (6.50) *193 (7.60) 9 (20) 62 350
ACS800-104-0005-3 R2i 401 (15.79) 165 (6.50) *193 (7.60) 9 (20) 62 350
ACS800-104-0006-3 R2i 401 (15.79) 165 (6.50) *193 (7.60) 9 (20) 62 350
ACS800-104-0009-3 R2i 401 (15.79) 165 (6.50) *193 (7.60) 9 (20) 62 350
ACS800-104-0011-3 R3i 466 (18.35) 173 (6.81) *232 (9.13) 12 (26) 62 820
ACS800-104-0016-3 R3i 466 (18.35) 173 (6.81) *232 (9.13) 12 (26) 62 820
ACS800-104-0020-3 R3i 466 (18.35) 173 (6.81) *232 (9.13) 12 (26) 62 820
ACS800-104-0025-3 R4i 525 (20.67) 240 (9.45) *252 (9.92) 15 (33) 62 1000
ACS800-104-0030-3 R4i 525 (20.67) 240 (9.45) *252 (9.92) 15 (33) 62 1000
ACS800-104-0040-3 R5i 673 (26.50) 265 (10.43) *276 (10.87) 23 (51) 65 2000
ACS800-104-0050-3 R5i 673 (26.50) 265 (10.43) *276 (10.87) 23 (51) 65 2000
ACS800-104-0060-3 R5i 673 (26.50) 265 (10.43) *276 (10.87) 23 (51) 65 2400
ACS800-104-0100-3 R7i **744 (29.29) **228 (8.98) **367 (14.45) **37 (82) 64 3300
ACS800-104-0120-3 R7i **744 (29.29) **228 (8.98) **367 (14.45) **37 (82) 64 4700
ACS800-104-0170-3 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 8200
ACS800-104-0210-3 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 8200
ACS800-104-0260-3 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 8200
ACS800-104-0320-3 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 10250
ACS800-104-0390-3 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 12300
ACS800-104-0510-3 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 14350
ACS800-104-0770-3 2×R8i ***1397 (55.00) ***245 (9.65) ***596 (23.46) ***150 (330) 74 24600
ACS800-104-1030-3 2×R8i ***1397 (55.00) ***245 (9.65) ***596 (23.46) ***150 (330) 74 28700
ACS800-104-1540-3 3×R8i ***1397 (55.00) ***245 (9.65) ***596 (23.46) ***150 (330) 76 43050
ACS800-104-2050-3 4×R8i ***1397 (55.00) ***245 (9.65) ***596 (23.46) ***150 (330) 76 57400
U
N
= 500 V
ACS800-104-0004-5 R2i 401 (15.79) 165 (6.50) *193 (7.60) 9 (20) 62 350
ACS800-104-0005-5 R2i 401 (15.79) 165 (6.50) *193 (7.60) 9 (20) 62 350
ACS800-104-0006-5 R2i 401 (15.79) 165 (6.50) *193 (7.60) 9 (20) 62 350
ACS800-104-0009-5 R2i 401 (15.79) 165 (6.50) *193 (7.60) 9 (20) 62 350
ACS800-104-0011-5 R2i 401 (15.79) 165 (6.50) *193 (7.60) 9 (20) 62 350
ACS800-104-0016-5 R3i 466 (18.35) 173 (6.81) *232 (9.13) 12 (26) 62 820
ACS800-104-0020-5 R3i 466 (18.35) 173 (6.81) *232 (9.13) 12 (26) 62 820
ACS800-104-0025-5 R3i 466 (18.35) 173 (6.81) *232 (9.13) 12 (26) 62 820
ACS800-104-0030-5 R4i 525 (20.67) 240 (9.45) *252 (9.92) 15 (33) 62 1000
ACS800-104-0040-5 R4i 525 (20.67) 240 (9.45) *252 (9.92) 15 (33) 62 1000
ACS800-104-0050-5 R5i 673 (26.50) 265 (10.43) *276 (10.87) 23 (51) 65 2000
ACS800-104-0060-5 R5i 673 (26.50) 265 (10.43) *276 (10.87) 23 (51) 65 2000
ACS800-104-0070-5 R5i 673 (26.50) 265 (10.43) *276 (10.87) 23 (51) 65 2400
ACS800-104-0100-5 R6i **744 (29.29) **228 (8.98) **367 (14.45) **37 (82) 64 2270
ACS800-104-0120-5 R7i **744 (29.29) **228 (8.98) **367 (14.45) **37 (82) 64 4530
ACS800-104-0140-5 R7i **744 (29.29) **228 (8.98) **367 (14.45) **37 (82) 64 4530
ACS800-104-0210-5 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 8200
ACS800-104-0260-5 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 8200
ACS800-104-0320-5 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 8200
ACS800-104-0400-5 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 10250
ACS800-104-0460-5 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 12300
