ABB ACS800-104

Technical data
113
ACS800-104-0610-5 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 14350
ACS800-104-0910-5 2×R8i ***1397 (55.00) ***245 (9.65) ***596 (23.46) ***150 (330) 74 24600
ACS800-104-1210-5 2×R8i ***1397 (55.00) ***245 (9.65) ***596 (23.46) ***150 (330) 74 28700
ACS800-104-1820-5 3×R8i ***1397 (55.00) ***245 (9.65) ***596 (23.46) ***150 (330) 76 43050
ACS800-104-2430-5 4×R8i ***1397 (55.00) ***245 (9.65) ***596 (23.46) ***150 (330) 76 57400
U
N
= 690 V
ACS800-104-0011-7 R4i 525 (20.67) 240 (9.45) *252 (9.92) 15 (33) 62 670
ACS800-104-0016-7 R4i 525 (20.67) 240 (9.45) *252 (9.92) 15 (33) 62 670
ACS800-104-0020-7 R4i 525 (20.67) 240 (9.45) *252 (9.92) 15 (33) 62 670
ACS800-104-0025-7 R4i 525 (20.67) 240 (9.45) *252 (9.92) 15 (33) 62 670
ACS800-104-0030-7 R4i 525 (20.67) 240 (9.45) *252 (9.92) 15 (33) 62 670
ACS800-104-0040-7 R4i 525 (20.67) 240 (9.45) *252 (9.92) 15 (33) 62 670
ACS800-104-0050-7 R5i 673 (26.50) 265 (10.43) *276 (10.87) 23 (51) 65 1330
ACS800-104-0060-7 R5i 673 (26.50) 265 (10.43) *276 (10.87) 23 (51) 65 1330
ACS800-104-0070-7 R6i **744 (29.29) **228 (8.98) **367 (14.45) **37 (82) 64 1570
ACS800-104-0100-7 R7i **744 (29.29) **228 (8.98) **367 (14.45) **37 (82) 64 2200
ACS800-104-0120-7 R7i **744 (29.29) **228 (8.98) **367 (14.45) **37 (82) 64 2200
ACS800-104-0210-7 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 4600
ACS800-104-0260-7 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 4600
ACS800-104-0320-7 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 6130
ACS800-104-0400-7 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 6130
ACS800-104-0440-7 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 7670
ACS800-104-0580-7 1×R8i 1397 (55.00) 245 (9.65) 596 (23.46) 150 (330) 72 9200
ACS800-104-0870-7 2×R8i ***1397 (55.00) ***245 (9.65) ***596 (23.46) ***150 (330) 74 15330
ACS800-104-1160-7 2×R8i ***1397 (55.00) ***245 (9.65) ***596 (23.46) ***150 (330) 74 18400
ACS800-104-1740-7 3×R8i ***1397 (55.00) ***245 (9.65) ***596 (23.46) ***150 (330) 76 27600
ACS800-104-2320-7 4×R8i ***1397 (55.00) ***245 (9.65) ***596 (23.46) ***150 (330) 76 36800
*Excluding control panel (optional)
**Excluding cooling fan. Refer to Dimensional drawings
***Single module only
Inverter module/unit
type
Frame
size
Height Width Depth Weight
Noise
level
DC
capacitance
mm (in.) mm (in.) mm (in.) kg (lbs) dBA µF
