ABB ACS800-104

Hardware description
23
Type code
Each module has a type designation label attached, containing e.g. the type code of
the unit. The type code contains information on the specifications and configuration
of the unit.
• The first 17 digits form the basic code. It describes the basic construction of the
unit. The fields in the basic code are separated with hyphens.
• The option codes follow the basic code. Each option code starts with an
identifying letter (common for the whole product series), followed by descriptive
digits. The option codes are separated by plus signs.
The main selections are described below. Not all options are necessarily available
for all types. For more information, contact your local ABB representative.
Basic code
Option codes
Digit no. Name/Description Alternatives Description
1…6 Product series ACS800
8…10 Construction 104 Inverter module
12…14 Size 0003 and up 3 kVA and up
16 Voltage rating 3 380/400/415 V. Nominal voltage: 400 V.
5 380/400/415/440/460/480/500 V. Nominal
voltage: 500 V.
7 525/575/600/660/690 V. Nominal voltage: 690 V.
Ident.
letter
Name/Description Alternatives Description
C C126 Speed-controlled cooling fan supplied
from the DC bus. Frame R8i only.
E Filters E205 Internal output (du/dt) filters. Frame R8i
only.
P Protection class P901 Coated circuit boards. This feature is
standard.
Q Safety features Q950 Prevention of unexpected start (built-in
AGPS board).
