ABB ACS800-104

Technical data
110
Frame R8i and multiples
ACS800-104-0016-7 R4i 17 19 15 15 11 11 7.5
ACS800-104-0020-7 R4i 22 28 18.5 20 15 15 11
ACS800-104-0025-7 R4i 25 38 22 23 18.5 19 15
ACS800-104-0030-7 R4i 33 44 30 30 22 22 18.5
ACS800-104-0040-7 R4i 36 54 30 34 30 27 22
ACS800-104-0050-7 R5i 51 68 45 46 37 34 30
ACS800-104-0060-7 R5i 57 84 55 52 45 42 37
ACS800-104-0070-7 R6i 65 104 55 62 55 52 45
ACS800-104-0100-7 R7i 88 130 75 84 75 65 55
ACS800-104-0120-7 R7i 105 176 90 101 90 88 75
Inverter unit type
Frame
size
Inverter modules
used
Nominal ratings
No-overload
use
Light-overload
use
Heavy-duty use
I
cont.max
A
I
max
A
P
cont.max
kW
I
2N
A
P
N
kW
I
2hd
A
P
hd
kW
U
N
= 400 V
ACS800-104-0170-3 1×R8i ACS800-104-0170-3 250 342 132 240 110 187 90
ACS800-104-0210-3 1×R8i ACS800-104-0210-3 292 400 160 280 132 218 110
ACS800-104-0260-3 1×R8i ACS800-104-0260-3 370 506 200 355 200 277 132
ACS800-104-0320-3 1×R8i ACS800-104-0320-3 469 642 250 450 250 351 200
ACS800-104-0390-3 1×R8i ACS800-104-0390-3 565 773 315 542 300 423 220
ACS800-104-0510-3 1×R8i ACS800-104-0510-3 741 1014 400 711 400 554 315
ACS800-104-0770-3 2×R8i ACS800-104-0390-3 1111 1521 630 1067 560 831 450
ACS800-104-1030-3 2×R8i ACS800-104-0510-3 1452 1988 900 1394 710 1086 560
ACS800-104-1540-3 3×R8i ACS800-104-0510-3 2156 2951 1250 2070 1120 1613 900
ACS800-104-2050-3 4×R8i ACS800-104-0510-3 2845 3894 1600 2731 1600 2128 1120
U
N
= 500 V
ACS800-104-0210-5 1×R8i ACS800-104-0210-5 250 363 160 240 160 187 110
ACS800-104-0260-5 1×R8i ACS800-104-0260-5 315 457 200 302 200 236 132
ACS800-104-0320-5 1×R8i ACS800-104-0320-5 365 530 250 350 250 273 160
ACS800-104-0400-5 1×R8i ACS800-104-0400-5 455 660 315 437 315 340 200
ACS800-104-0460-5 1×R8i ACS800-104-0460-5 525 762 355 504 355 393 250
ACS800-104-0610-5 1×R8i ACS800-104-0610-5 700 1016 500 672 450 524 355
ACS800-104-0910-5 2×R8i ACS800-104-0460-5 1050 1524 710 1008 710 785 500
ACS800-104-1210-5 2×R8i ACS800-104-0610-5 1372 1991 900 1317 900 1026 710
ACS800-104-1820-5 3×R8i ACS800-104-0610-5 2037 2956 1400 1956 1400 1524 1120
ACS800-104-2430-5 4×R8i ACS800-104-0610-5 2688 3901 2000 2580 1800 2011 1400
U
N
= 690 V
ACS800-104-0210-7 1×R8i ACS800-104-0210-7 170 254 160 163 160 127 90
ACS800-104-0260-7 1×R8i ACS800-104-0260-7 215 322 200 206 200 161 132
ACS800-104-0320-7 1×R8i ACS800-104-0320-7 289 432 250 277 250 216 160
ACS800-104-0400-7 1×R8i ACS800-104-0400-7 336 503 315 323 315 251 200
ACS800-104-0440-7 1×R8i ACS800-104-0440-7 382 571 355 367 355 286 250
ACS800-104-0580-7 1×R8i ACS800-104-0580-7 486 727 450 467 450 364 315
ACS800-104-0870-7 2×R8i ACS800-104-0440-7 729 1091 710 700 710 545 500
ACS800-104-1160-7 2×R8i ACS800-104-0580-7 953 1425 900 914 900 713 630
ACS800-104-1740-7 3×R8i ACS800-104-0580-7 1414 2116 1400 1358 1400 1058 900
ACS800-104-2320-7 4×R8i ACS800-104-0580-7 1866 2792 1800 1792 1800 1396 1400
PDM-00184674
Inverter module type
Frame
size
Nominal ratings No-overload use Light-overload use Heavy-duty use
I
cont.max
A
I
max
A
P
cont.max
kW
I
2N
A
P
N
kW
I
2hd
A
P
hd
kW
