ACS800-104 ordering information
93
ACS800-104 ordering information
What this chapter contains
This chapter lists the components and accessories specific to the ACS800-104
inverter module range.
See the ACS800 Product Reference (3AFE 64813340 [English]) for generic
equipment for the ACS 800 product family such as control panels, I/O options,
application programs and PC tools.
Inverter modules
The following tables list the ACS800-104 inverter modules available.
Notes:
• The application program for the modules must be specified when ordering
• Control panel (CDP 312R) is not included
• Frame R6i and R7i modules require an external fan
• The modules have coated circuit boards as standard equipment.
Frame sizes R2i to R7i
Option key: +Q950: Prevention of unexpected start (for more information, see the
document ACS 800 MultiDrive; Planning the Electrical Installation [3AFE 64783742,
English]).
Inverter modules (R2i to R7i)
ACS800-104 type Frame size
P
cont.max
(kW)
Order code
(no options) +Q950
U
N
= 400 V (380/400/415 V)
ACS800-104-0003-3 R2i 1.5 64685724 64741730
ACS800-104-0004-3 R2i 2.2 64704338 64751972
ACS800-104-0005-3 R2i 3 64704346 64751999
ACS800-104-0006-3 R2i 4 64704354 64752162
ACS800-104-0009-3 R2i 5.5 64704362 64752243
ACS800-104-0011-3 R3i 7.5 64702262 64752464
ACS800-104-0016-3 R3i 11 64704478 64752529
ACS800-104-0020-3 R3i 15 64704486 64752723
ACS800-104-0025-3 R4i 22 64702271 64752812
ACS800-104-0030-3 R4i 30 64704524 64752855
ACS800-104-0040-3 R5i 37 64702246 64759833
ACS800-104-0050-3 R5i 45 64702254 64759922
ACS800-104-0060-3 R5i 55 64704320 64759965
ACS800-104-0100-3 R7i 75 68253390 68260400
ACS800-104-0120-3 R7i 90 68253411 68260418
U
N
= 500 V (380/400/415/440/460/480/500 V)
ACS800-104-0004-5 R2i 2.2 64704419 64752065
