What this chapter contains
This chapter contains the technical data for the ACS800-104 inverter modules and
associated optional equipment.
IEC ratings
Frame R2i to R7i
Inverter module type
Frame
size
Nominal ratings No-overload use Light-overload use Heavy-duty use
I
cont.max
A
I
max
A
P
cont.max
kW
I
2N
A
P
N
kW
I
2hd
A
P
hd
kW
U
N
= 400 V
ACS800-104-0003-3 R2i 5.1 6.5 1.5 4.7 1.5 3.4 1.1
ACS800-104-0004-3 R2i 6.5 8.2 2.2 5.9 2.2 4.3 1.5
ACS800-104-0005-3 R2i 8.5 10.8 3 7.7 3.0 5.7 2.2
ACS800-104-0006-3 R2i 10.9 13.8 4 10.2 4.0 7.5 3.0
ACS800-104-0009-3 R2i 13.9 17.6 5.5 12.7 5.5 9.3 4.0
ACS800-104-0011-3 R3i 19 24 7.5 18 7.5 14 5.5
ACS800-104-0016-3 R3i 25 32 11 24 11 19 7.5
ACS800-104-0020-3 R3i 34 46 15 31 15 23 11
ACS800-104-0025-3 R4i 44 62 22 41 18.5 32 15
ACS800-104-0030-3 R4i 55 72 30 50 22 37 18.5
ACS800-104-0040-3 R5i 72 86 37 69 30 49 22
ACS800-104-0050-3 R5i 86 112 45 80 37 60 30
ACS800-104-0060-3 R5i 103 138 55 94 45 69 37
ACS800-104-0100-3 R7i 147 224 75 141 75 112 55
ACS800-104-0120-3 R7i 178 294 90 171 90 147 75
U
N
= 500 V
ACS800-104-0004-5 R2i 4.9 6.5 2.2 4.5 2.2 3.4 1.5
ACS800-104-0005-5 R2i 6.2 8.2 3 5.6 3.0 4.2 2.2
ACS800-104-0006-5 R2i 8.1 10.8 4 7.7 4.0 5.6 3.0
ACS800-104-0009-5 R2i 10.5 13.8 5.5 10.0 5.5 7.5 4.0
ACS800-104-0011-5 R2i 13.2 17.6 7.5 12.0 7.5 9.2 5.5
ACS800-104-0016-5 R3i 19 24 11 18 11 13 7.5
ACS800-104-0020-5 R3i 25 32 15 23 15 18 11
ACS800-104-0025-5 R3i 34 46 18.5 31 18.5 23 15
ACS800-104-0030-5 R4i 42 62 22 39 22 32 18.5
ACS800-104-0040-5 R4i 48 72 30 44 30 36 22
ACS800-104-0050-5 R5i 65 86 37 61 37 50 30
ACS800-104-0060-5 R5i 79 112 45 75 45 60 37
ACS800-104-0070-5 R5i 96 138 55 88 55 69 45
ACS800-104-0100-5 R6i 112 168 75 108 75 84 55
ACS800-104-0120-5 R7i 135 224 90 130 90 112 75
ACS800-104-0140-5 R7i 164 270 110 157 110 135 90
U
N
= 690 V
ACS800-104-0011-7 R4i 13 14 11 11.5 7.5 8.5 5.5
