ABB ACS800-104

Technical data
115
ACS800-104-0260-5 1×R8i 3300 (11300) 1280 (750) 575 (90) 1150 (180) 920 (140) 1840 (290) 150
ACS800-104-0320-5 1×R8i 3900 (13300) 1280 (750) 575 (90) 1150 (180) 920 (140) 1840 (290) 150
ACS800-104-0400-5 1×R8i 4700 (16100) 1280 (750) 575 (90) 1150 (180) 920 (140) 1840 (290) 150
ACS800-104-0460-5 1×R8i 5700 (19500) 1280 (750) 575 (90) 1150 (180) 920 (140) 1840 (290) 150
ACS800-104-0610-5 1×R8i 7700 (26300) 1280 (750) 575 (90) 1150 (180) 920 (140) 1840 (290) 150
ACS800-104-0910-5 2×R8i 11300 (38600) 2560 (1510) 960 (150) 1920 (295) 1536 (240) 3072 (475) 180
ACS800-104-1210-5 2×R8i 14900 (50900) 2560 (1510) 960 (150) 1920 (295) 1536 (240) 3072 (475) 180
ACS800-104-1820-5 3×R8i 22000 (75100) 3840 (2260) 1440 (225) 2880 (445) 2304 (355) 4608 (715) 180
ACS800-104-2430-5 4×R8i 28900 (98700) 5120 (3010) 1920 (295) 3840 (595) 3072 (475) 6144 (950) 180
U
N
= 690 V
ACS800-104-0011-7 R4i 300 (1030) 103 (61) 300 (47) 600 (93) 480 (74) 960 (149) 12
ACS800-104-0016-7 R4i 340 (1160) 103 (61) 300 (47) 600 (93) 480 (74) 960 (149) 12
ACS800-104-0020-7 R4i 440 (1500) 103 (61) 300 (47) 600 (93) 480 (74) 960 (149) 12
ACS800-104-0025-7 R4i 530 (1810) 103 (61) 300 (47) 600 (93) 480 (74) 960 (149) 12
ACS800-104-0030-7 R4i 610 (2080) 103 (61) 300 (47) 600 (93) 480 (74) 960 (149) 12
ACS800-104-0040-7 R4i 690 (2360) 103 (61) 300 (47) 600 (93) 480 (74) 960 (149) 12
ACS800-104-0050-7 R5i 840 (2870) 168 (99) 400 (62) 800 (124) 640 (99) 1280 (198) 17
ACS800-104-0060-7 R5i 1010 (3450) 168 (99) 400 (62) 800 (124) 640 (99) 1280 (198) 17
ACS800-104-0070-7 R6i 1100 (3760) 480 (283) 325 (50) 650 (101) 520 (81) 1040 (161) 67
ACS800-104-0100-7 R7i 1500 (5120) 480 (283) 325 (50) 650 (101) 520 (81) 1040 (161) 67
ACS800-104-0120-7 R7i 1800 (6150) 480 (283) 325 (50) 650 (101) 520 (81) 1040 (161) 67
ACS800-104-0210-7 1×R8i 3300 (11300) 1280 (750) 575 (90) 1150 (180) 920 (140) 1840 (290) 150
ACS800-104-0260-7 1×R8i 4000 (13700) 1280 (750) 575 (90) 1150 (180) 920 (140) 1840 (290) 150
ACS800-104-0320-7 1×R8i 4600 (15700) 1280 (750) 575 (90) 1150 (180) 920 (140) 1840 (290) 150
ACS800-104-0400-7 1×R8i 5200 (17800) 1280 (750) 575 (90) 1150 (180) 920 (140) 1840 (290) 150
ACS800-104-0440-7 1×R8i 6800 (23200) 1280 (750) 575 (90) 1150 (180) 920 (140) 1840 (290) 150
ACS800-104-0580-7 1×R8i 7400 (25300) 1280 (750) 575 (90) 1150 (180) 920 (140) 1840 (290) 150
ACS800-104-0870-7 2×R8i 12900 (44100) 2560 (1510) 960 (150) 1920 (295) 1536 (240) 3072 (475) 180
ACS800-104-1160-7 2×R8i 14400 (49200) 2560 (1510) 960 (150) 1920 (295) 1536 (240) 3072 (475) 180
ACS800-104-1740-7 3×R8i 21300 (72800) 3840 (2260) 1440 (225) 2880 (445) 2304 (355) 4608 (715) 180
ACS800-104-2320-7 4×R8i 28100 (96000) 5120 (3010) 1920 (295) 3840 (595) 3072 (475) 6144 (950) 180
Inverter module/
unit type
Frame
size
Power loss
Nominal air
flow
Minimum effective area
of air inlet
Minimum effective area
of air outlet
Max. pressure
drop of
cabinet at
nominal air
flow
unfiltered
with
Luftfilter/
airTex G150
unfiltered
with
Luftfilter/
airTex G150
W (Btu/h) m
3
/h (ft
3
/min) cm
2
(in
2
)cm
2
(in
2
)cm
2
(in
2
)cm
2
(in
2
)Pa
