ABB ACS800-104

ACS800-104 ordering information
97
0060-7
2
170M
2682
125A
1000V
10029813 1
OFAX
00S2L
2×125A
690V
58065749 1 64089650
0070-7
2
170M
2682
125A
1000V
10029813 1
OFAX
00S2L
2×125A
690V
58065749 1 64089684
0100-7
0120-7
2
170M
4700
200A
1000V
10001731 1
OFAX
1S2
2×250A
690V
10029082 1
64349643 (230V)
64349651 (115V)
0210-7
0260-7
0320-7
0400-7
2
170M
6205
630A
1000V
10001773 2
OFASA
3
630A
690V
35009841 1 64808796
0440-7 2
170M
6203
800A
1250V
10029881 2
OFASA
3
630A
690V
35009841 1 64808842
0580-7 2
170M
8650
1000A
1000V
64673769 2
OFASA
3
630A
690V
35009841 1 64808842
0870-7 4
170M
6203
800A
1250V
10029881 4
OFASA
3
630A
690V
35009841 1 64808851
1160-7 4
170M
8650
1000A
1000V
64673769 4
OFASA
3
630A
690V
35009841 1 64808851
1740-7 6
170M
8650
1000A
1000V
64673769 6
OFASA
3
630A
690V
35009841 1 64808877
2320-7 8
170M
8650
1000A
1000V
64673769 8
OFASA
3
630A
690V
35009841 2 64808851
Switch fuse kit contents
Order
code
Kit contents
64089561
1–Switch Fuse (OESA00-160D2PL) • 1–Mounting Frame for 4 aux. contacts • 4–Aux. Contact (2–NO,
1–NO gold-plated, 1–NC) • 1–Resistor (ZRF 30×167,5) • 1–Contactor (LP1-D501124) • 1–Relay, 11-
pole • 1–Relay Socket
64089650
1–Switch Fuse (OESA00-160D2PL) • 1–Mounting Frame for 4 aux. contacts • 4–Aux. Contact (2–NO,
1–NO gold-plated, 1–NC)
64089684
1–Switch Fuse (OESA00D2PL) • 1–Mounting Frame for 4 aux. contacts • 4–Aux. Contact (2–NO, 1–
NO gold-plated, 1–NC) • 2–Resistor (ZRF 30×165) • 1–Contactor (BC 25-30-10/24) • 1–Relay, 11-pole
• 1–Relay Socket
64349619
1–Switch Fuse (OESA250DR2PL-21/1, including: locking device, charging contacts, 1–NC contact, 1–
NO contact) • 1–Aux. Contact (OZXK 2, including: 2–NC contact, 2–NO contact) • 2–Resistor (ZRF
30×167,5) • 1–Charging Monitoring Unit (NCHM-21C) • 1–Wire Set, OESA control wiring
64349627
1–Switch Fuse (OESA250DR2PL-X, including: locking device, charging contacts, 1–NC contact, 1–NO
contact) • 1–Aux. Contact (OZXK 2, including: 2-NC contact, 2–NO contact) • 2–Resistor (ZRF
30×167,5) • 1–Charging Monitoring Unit (NCHM-11C) • 1–Wire Set, OESA control wiring
64349643
1–Switch Fuse (OESA250DR2PL-21/1, including: locking device, charging contacts, 1–NC contact, 1–
NO contact) • 1–Aux. Contact (OZXK 2, including: 2-NC contact, 2–NO contact) • 2–Resistor (ZRF
30×165) • 1–Charging Monitoring Unit (NCHM-21C) • 1–Wire Set, OESA control wiring
64349651
1–Switch Fuse (OESA250DR2PL-X, including: locking device, charging contacts, 1–NC contact, 1–NO
contact) • 1–Aux. Contact (OZXK 2, including: 2-NC contact, 2–NO contact) • 2–Resistor (ZRF 30×165)
• 1–Charging Monitoring Unit (NCHM-11C) • 1–Wire Set, OESA control wiring
64808796
1–Switch Fuse (OESL630/32D02) • 2–Resistor (ZRF 30×167,5) • 1–Switch fuse controller (ASFC-01C)
64808800
1–Switch Fuse (OESL630/32D04) • 4–Resistor (ZRF 30×167,5) • 1–Switch fuse controller (ASFC-01C)
64808826
1–Switch Fuse (OESL630/32D06) • 6–Resistor (ZRF 30×167,5) • 1–Switch fuse controller (ASFC-01C)
64808842
1–Switch Fuse (OESL630/32D02) • 2–Resistor (ZRF 30×165) • 1–Switch fuse controller (ASFC-01C)
64808851
1–Switch Fuse (OESL630/32D04) • 4–Resistor (ZRF 30×165) • 1–Switch fuse controller (ASFC-01C)
64808877
1–Switch Fuse (OESL630/32D06) • 6–Resistor (ZRF 30×165) • 1–Switch fuse controller (ASFC-01C)
DC fuses and fuse bases/Switch fuse kits for inverter modules
Module type
ACS800-104-…
DC fuse DC fuse base
Switch fuse kit
(see below)
Qty Type Info
Order
code
Qty Type Info
Order
code
Qty Order code
