ABB ACS880-104

Parameters 237
In1P Start; In2 Stop;
In3 Dir
The sources of the start and stop commands are selected by
parameters 20.08 Ext2 in1 source and 20.09 Ext2 in2 source.
The source selected by 20.10 Ext2 in3 source determines the
direction. The state transitions of the source bits are
interpreted as follows:
Note: The start signal is always edge-triggered with this
setting regardless of parameter 20.07 Ext2 start trigger type.
5
In1P Start fwd; In2P
Start rev; In3 Stop
The sources of the start and stop commands are selected by
parameters 20.08 Ext2 in1 source, 20.09 Ext2 in2 source and
20.10 Ext2 in3 source. The state transitions of the source bits
are interpreted as follows:
Note: The start signal is always edge-triggered with this
setting regardless of parameter 20.07 Ext2 start trigger type.
6
Control panel The start and stop commands are taken from the control
panel.
11
Fieldbus A The start and stop commands are taken from fieldbus adapter
A.
Note: The start signal is always level-triggered with this
setting regardless of parameter 20.07 Ext2 start trigger type.
12
Embedded fieldbus The start and stop commands are taken from the embedded
fieldbus interface.
Note: The start signal is always level-triggered with this
setting regardless of parameter 20.07 Ext2 start trigger type.
14
M/F link The start and stop commands are taken from another drive
through the master/follower link.
Note: The start signal is always level-triggered with this
setting regardless of parameter 20.07 Ext2 start trigger type.
15
Application
Program
The start and stop commands are taken from the application
program control word (parameter 06.02 Application control
word).
Note: The start signal is always level-triggered with this
setting regardless of parameter 20.07 Ext2 start trigger type.
21
ATF Reserved. 22
DDCS controller The start and stop commands are taken from an external
(DDCS) controller.
Note: The start signal is always level-triggered with this
setting regardless of parameter 20.07 Ext2 start trigger type.
16
No. Name/Value Description Def/FbEq16
State of
source 1
(20.08)
State of
source 2
(20.09)
State of
source 3
(20.10)
Command
0
-
> 1 1 0 Start forward
0
-
> 1 1 1 Start reverse
Any 0 Any Stop
State of
source 1
(20.08)
State of
source 2
(20.09)
State of
source 3
(20.10)
Command
0
-
> 1 Any 1 Start forward
Any 0
-
> 1 1 Start reverse
Any Any 0 Stop
