ABB ACS880-104

236 Parameters
20.06 Ext2 commands Selects the source of start, stop and direction commands for
external control location 2 (EXT2).
See also parameters 20.07…20.10.
Not selected
Not selected No start or stop command sources selected. 0
In1 Start The source of the start and stop commands is selected by
parameter 20.08 Ext2 in1 source. The state transitions of the
source bits are interpreted as follows:
1
In1 Start; In2 Dir The source selected by 20.08 Ext2 in1 source is the start
signal; the source selected by 20.09 Ext2 in2 source
determines the direction. The state transitions of the source
bits are interpreted as follows:
2
In1 Start fwd; In2
Start rev
The source selected by 20.08 Ext2 in1 source is the forward
start signal; the source selected by 20.09 Ext2 in2 source is
the reverse start signal. The state transitions of the source
bits are interpreted as follows:
3
In1P Start; In2 Stop The sources of the start and stop commands are selected by
parameters 20.08 Ext2 in1 source and 20.09 Ext2 in2 source.
The state transitions of the source bits are interpreted as
follows:
Note: The start signal is always edge-triggered with this
setting regardless of parameter 20.07 Ext2 start trigger type.
4
No. Name/Value Description Def/FbEq16
State of source 1 (20.08) Command
0
-
> 1 (20.07 = Edge)
1 (20.07 = Level)
Start
0Stop
State of source 1
(20.08)
State of source 2
(20.09)
Command
0 Any Stop
0
-
> 1 (20.07 = Edge)
1 (20.07 = Level)
0 Start forward
1 Start reverse
State of source 1
(20.08)
State of source 2
(20.09)
Command
00Stop
0
-
> 1 (20.07 = Edge)
1 (20.07 = Level)
0 Start forward
0
0
-
> 1 (20.07 = Edge)
1 (20.07 = Level)
Start reverse
11Stop
State of source 1
(20.08)
State of source 2
(20.09)
Command
0
-
> 1 1 Start
Any 0 Stop
