Parameters 241
20.25 Jogging enable Selects the source for a jog enable signal.
(The sources for jogging activation signals are selected by
parameters 20.26 Jogging 1 start source and 20.27 Jogging 2
start source.)
1 = Jogging is enabled.
0 = Jogging is disabled.
Note: Jogging can be enabled only when no start command
from an external control location is active. On the other hand,
if jogging is already enabled, the drive cannot be started from
an external control location (apart from inching commands
through fieldbus).
See section Jogging (page 92).
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
Other [bit] Source selection (see Terms and abbreviations on page 148). -
20.26 Jogging 1 start
source
If enabled by parameter 20.25 Jogging enable, selects the
source for the activation of jogging function 1. (Jogging
function 1 can also be activated through fieldbus regardless
of parameter 20.25.)
1 = Jogging 1 active.
Note: If both jogging 1 and 2 are activated, the one that was
activated first has priority.
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (
10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
Other [bit] Source selection (see Terms and abbreviations on page 148). -
No. Name/Value Description Def/FbEq16
