ABB ACS880-104

Parameters 255
Enabled (init at
stop/power-up)
When enabled, the motor potentiometer first adopts the value
defined by parameter 22.72 Motor potentiometer initial value.
When the drive is running, the value can be adjusted from the
up and down sources defined by parameters 22.73 Motor
potentiometer up source and 22.74 Motor potentiometer
down source.
A stop or a power cycle will reset the motor potentiometer to
the initial value (22.72).
1
Enabled (resume
always)
As Enabled (init at stop/power-up), but the motor
potentiometer value is retained over a stop or a power cycle.
2
22.72 Motor
potentiometer initial
value
Defines an initial value (starting point) for the motor
potentiometer. See the selections of parameter 22.71 Motor
potentiometer function.
0.00
-32768.00 …
32767.00
Initial value for motor potentiometer. 1 = 1
22.73 Motor
potentiometer up
source
Selects the source of motor potentiometer up signal.
0 = No change
1 = Increase motor potentiometer value. (If both the up and
down sources are on, the potentiometer value will not
change.)
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
Other [bit] Source selection (see Terms and abbreviations on page 148). -
22.74 Motor
potentiometer down
source
Selects the source of motor potentiometer down signal.
0 = No change
1 = Decrease motor potentiometer value. (If both the up and
down sources are on, the potentiometer value will not
change.)
For the selections, see parameter 22.73 Motor potentiometer
up source.
Not selected
22.75 Motor
potentiometer ramp
time
Defines the change rate of the motor potentiometer. This
parameter specifies the time required for the motor
potentiometer to change from minimum (22.76) to maximum
(22.77). The same change rate applies in both directions.
60.0 s
0.0 … 3600.0 s Motor potentiometer change time. 10 = 1 s
22.76 Motor
potentiometer min
value
Defines the minimum value of the motor potentiometer. -1500.00
-32768.00 …
32767.00
Motor potentiometer minimum. 1 = 1
No. Name/Value Description Def/FbEq16
