32 Quick start-up guide
Set the correct date:
• Use and to move the cursor left
and right.
• Use and to change the value.
• Press (Save) to accept the new
setting.
Check/adjust all the remaining settings in the
Date & time menu.
The Show clock setting determines whether
the time is shown at all times in the bottom
pane of the display.
After you have made the settings, press
(Back or Exit) repeatedly until the
Home view (right) reappears.
2 – Electrical settings
Switch to local control to ensure that external
control is disabled by pressing the
key. Local control is indicated by the text
“Local” in the top pane.
Open the main Menu by pressing
(Menu).
Remote 0.0 rpm
0.00
0.00
Motor torque%
%
0.0
Motor current
A
Motor speed used
rpm
Options
12:35
Menu
Local 0.0 rpm
0.00
0.00
Motor torque%
%
0.0
Motor current
A
Motor speed used
rpm
Options
12:36
Menu
Local 0.0 rpm
Menu
Parameters
Assistants
Energy efficiency
Event log
Exit
12:36
Select
