380 Parameters
50.47 FBA B actual value
1
Displays raw (unmodified) actual value ACT1 sent by fieldbus
adapter B to the master (PLC) if debugging is enabled by
parameter 50.42 FBA B debug mode.
This parameter is read-only.
-
-2147483648 …
2147483647
Raw ACT1 sent by fieldbus adapter B to master. -
50.48 FBA B actual value
2
Displays raw (unmodified) actual value ACT2 sent by fieldbus
adapter B to the master (PLC) if debugging is enabled by
parameter 50.42 FBA B debug mode.
This parameter is read-only.
-
-2147483648 …
2147483647
Raw ACT2 sent by fieldbus adapter B to master. -
50.51 FBA B timelevel sel Selects the communication time levels.
In general, lower time levels of read/write services reduce
CPU load. The table below shows the time levels of the
read/write services for cyclic high and cyclic low data with
each parameter setting.
* Cyclic high data consists of fieldbus Status word, Act1 and
Act2.
** Cyclic low data consists of the parameter data mapped to
parameter groups 55 FBA B data in and 56 FBA B data out,
and acyclic data.
Control word, Ref1 and Ref2 are handled as interrupts
generated on receipt of cyclic high messages.
Normal
Normal Normal speed. 0
Fast Fast speed. 1
Very fast Very fast speed. 2
Monitoring Low speed. Optimized for PC tool communication and
monitoring usage.
3
No. Name/Value Description Def/FbEq16
Selection Cyclic high * Cyclic low **
Monitoring 10 ms 2 ms
Normal 2 ms 10 ms
Fast 500 µs 2 ms
Very fast 250 µs 2 ms
