ABB ACS880-104

Parameters 379
50.38 FBA B actual 2 type Selects the type/source and scaling of actual value 2
transmitted to the fieldbus network through fieldbus adapter
B.
See parameter 50.08 FBA A actual 2 type.
Auto
50.39 FBA B SW
transparent source
Selects the source of the fieldbus status word when the
fieldbus adapter is set to a transparent communication profile
eg. by its configuration parameters (group 54 FBA B settings).
Not selected
Not selected No source selected. -
Other Source selection (see Terms and abbreviations on page 148). -
50.40 FBA B act1
transparent source
When parameter 50.37 FBA B actual 1 type is set to
Transparent or General, this parameter selects the source of
actual value 1 transmitted to the fieldbus network through
fieldbus adapter B.
Not selected
Not selected No source selected. -
Other Source selection (see Terms and abbreviations on page 148). -
50.41 FBA B act2
transparent source
When parameter 50.38 FBA B actual 2 type is set to
Transparent or General, this parameter selects the source of
actual value 2 transmitted to the fieldbus network through
fieldbus adapter B.
Not selected
Not selected No source selected. -
Other Source selection (see Terms and abbreviations on page 148). -
50.42 FBA B debug mode Enables the display of raw (unmodified) data received from
and sent to fieldbus adapter B in parameters 50.43…50.48.
This functionality should only be used for debugging.
Disable
Disable Display of raw data from fieldbus adapter B disabled. 0
Fast Display of raw data from fieldbus adapter B enabled. 1
50.43 FBA B control word Displays the raw (unmodified) control word sent by the
master (PLC) to fieldbus adapter B if debugging is enabled by
parameter 50.42 FBA B debug mode.
This parameter is read-only.
-
00000000h …
FFFFFFFFh
Control word sent by master to fieldbus adapter B. -
50.44 FBA B reference 1 Displays raw (unmodified) reference REF1 sent by the master
(PLC) to fieldbus adapter B if debugging is enabled by
parameter 50.42 FBA B debug mode.
This parameter is read-only.
-
-2147483648 …
2147483647
Raw REF1 sent by master to fieldbus adapter B. -
50.45 FBA B reference 2
Displays raw (unmodified) reference REF2 sent by the master
(PLC) to fieldbus adapter B if debugging is enabled by
parameter 50.42 FBA B debug mode.
This parameter is read-only.
-
-2147483648 …
2147483647
Raw REF2 sent by master to fieldbus adapter B. -
50.46 FBA B status word Displays the raw (unmodified) status word sent by fieldbus
adapter B to the master (PLC) if debugging is enabled by
parameter 50.42 FBA B debug mode.
This parameter is read-only.
-
00000000h …
FFFFFFFFh
Status word sent by fieldbus adapter B to master. -
No. Name/Value Description Def/FbEq16
