408 Parameters
CW 16bit Control Word (16 bits) 1
SW 16bit Status Word (16 bits) 4
Act1 16bit Actual value ACT1 (16 bits) 5
Act2 16bit Actual value ACT2 (16 bits) 6
Other Source selection (see Terms and abbreviations on page 148). -
61.52 Data set 11 data 2
selection
Preselects the data to be sent as word 2 of data set 11 to the
external controller.
See also parameter 61.102 Data set 11 data 2 value.
For the selections, see parameter 61.51 Data set 11 data 1
selection.
None
61.53 Data set 11 data 3
selection
Preselects the data to be sent as word 3 of data set 11 to the
external controller.
See also parameter 61.103 Data set 11 data 3 value.
For the selections, see parameter 61.51 Data set 11 data 1
selection.
None
61.54 Data set 13 data 1
selection
See parameter 61.51 Data set 11 data 1 selection. None
…… … …
61.74 Data set 25 data 3
selection
See parameter 61.51 Data set 11 data 1 selection. None
61.95 Data set 2 data 1
value
Displays (in integer format) the data to be sent to the external
controller as word 1 of data set 2.
If no data has been preselected by 61.45 Data set 2 data 1
selection, the value to be sent can be written directly into this
parameter.
0
0…65535 Data to be sent as word 1 of data set 2.
61.96 Data set 2 data 2
value
Displays (in integer format) the data to be sent to the external
controller as word 2 of data set 2.
If no data has been preselected by 61.46 Data set 2 data 2
selection, the value to be sent can be written directly into this
parameter.
0
0…65535 Data to be sent as word 2 of data set 2.
61.97 Data set 2 data 3
value
Displays (in integer format) the data to be sent to the external
controller as word 3 of data set 2.
If no data has been preselected by 61.47 Data set 2 data 3
selection, the value to be sent can be written directly into this
parameter.
0
0…65535 Data to be sent as word 3 of data set 2.
…… … …
61.100 Data set 4 data 3
value
Displays (in integer format) the data to be sent to the external
controller as word 3 of data set 4.
If no data has been selected by 61.50
Data set 4 data 3
selection, the value to be sent can be written directly into this
parameter.
0
0…65535 Data to be sent as word 3 of data set 4.
No. Name/Value Description Def/FbEq16
