Parameters 409
61.101 Data set 11 data 1
value
Displays (in integer format) the data to be sent to the external
controller as word 1 of data set 11.
If no data has been preselected by 61.51 Data set 11 data 1
selection, the value to be sent can be written directly into this
parameter.
0
0…65535 Data to be sent as word 1 of data set 11.
61.102 Data set 11 data 2
value
Displays (in integer format) the data to be sent to the external
controller as word 2 of data set 11.
If no data has been preselected by 61.52 Data set 11 data 2
selection, the value to be sent can be written directly into this
parameter.
0
0…65535 Data to be sent as word 2 of data set 11.
61.103 Data set 11 data 3
value
Displays (in integer format) the data to be sent to the external
controller as word 3 of data set 11.
If no data has been selected by 61.53 Data set 11 data 3
selection, the value to be sent can be written directly into this
parameter.
0
0…65535 Data to be sent as word 3 of data set 11.
61.104 Data set 13 data 1
value
Displays (in integer format) the data to be sent to the external
controller as word 1 of data set 13.
If no data has been selected by 61.54 Data set 13 data 1
selection, the value to be sent can be written directly into this
parameter.
0
0…65535 Data to be sent as word 1 of data set 13.
…… … …
61.124 Data set 25 data 3
value
Displays (in integer format) the data to be sent to the external
controller as word 3 of data set 25.
If no data has been selected by 61.74 Data set 25 data 3
selection, the value to be sent can be written directly into this
parameter.
0
0…65535 Data to be sent as word 3 of data set 25.
61.151 INU-LSU data set
10 data 1 sel
(Parameters 61.151…61.203 only visible when supply unit
control activated by 95.20)
Parameters 61.151…61.153 preselect data to be sent in data
set 10 to another converter (typically the supply unit of the
drive).
Parameters 61.201…61.203 display the data to be sent to the
other converter. If no data has been preselected, the value to
be sent can be written directly into these parameters.
For example, this parameter preselects the data for word 1 of
data set 10. Parameter 61.201 INU-LSU data set 10 data 1
value displays the selected data in integer format. If no data is
preselected, the value to be sent can be written directly into
parameter 61.201.
LSU CW
None None. 0
LSU CW Control word for the supply unit. 22
DC voltage
reference
94.20 DC voltage reference (page 472). 24084
Reactive power
reference
94.30 Reactive power reference (page 473). 24094
Other Source selection (see Terms and abbreviations on page 148). -
No. Name/Value Description Def/FbEq16
