ABB ACS880-104

438 Parameters
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 9
ESP CW bit 9 Parameter 74.01 ESP control word, bit-9 status controls
enable/disable status of the function.
10
Other Source selection (see Terms and abbreviations on page 148). -
80.10 U/F Curve enable Defines the source for the U/F curve enable signal.
When this parameter is enabled, the function will control
motor flux reference based on user settings with parameters
80.11...80.18. The requested change in voltage reference is
internally converted to motor flux reference correction at a
corresponding frequency point. The effect of applied settings
can be monitored through signals 80.80 Flux correction and
80.81 Flux reference.
For further information, see Motor voltage control (page 58).
ESP CW bit
10
Not selected U/F curve enable signal is disabled. 0
Selected U/F curve enable signal is enabled. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 8
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 9
ESP CW bit 10 Parameter 74.01 ESP control word, bit-10 status controls
enable/disable status of the function.
10
Other Source selection (see Terms and abbreviations on page 148). -
80.11 Frequency point 1 Defines frequency point 1 in the custom user U/F curve. 10.00
2.00...600.00 Hz Frequency point 1. 10 = 1Hz
80.12 Frequency point 2 Defines frequency point 2 in the custom user U/F curve. 20.00
2.00...600.00 Hz Frequency point 2. 10 = 1Hz
80.13 Frequency point 3 Defines frequency point 3 in the custom user U/F curve. 30.00
2.00...600.00 Hz Frequency point 3. 10 = 1Hz
80.14 Frequency point 4 Defines frequency point 4 in the custom user U/F curve. 40.00
2.00...600.00 Hz Frequency point 4. 10 = 1Hz
80.15 Frequency point 5 Defines frequency point 5 in the custom user U/F curve. 45.00
2.00...600.00 Hz Frequency point 5. 10 = 1Hz
80.16 Frequency point 6 Defines frequency point 6 in the custom user U/F curve. 50.00
2.00...600.00 Hz Frequency point 6. 10 = 1Hz
80.17 Frequency point 7 Defines frequency point 7 in the custom user U/F curve. 55.00
2.00...600.00 Hz Frequency point 7. 10 = 1Hz
80.18 Frequency point 8 Defines frequency point 8 in the custom user U/F curve. 60.00
2.00...600.00 Hz Frequency point 8. 10 = 1Hz
80.21 Additive voltage 1 Defines voltage additive point 1 in the custom user U/F curve. 0.00
-100.00...100.00 % Additive voltage 1. 10 = 1%
No. Name/Value Description Def/FbEq16
