ABB ACS880-107 Series

DC capacit-
ance
Module-specific DC fusesInverter module(s) used
Inverter unit type
μFTypeQtyTypeQty
27000Cooper Bussmann 170M65486ACS880-104-0530A-73ACS880-107-1540A-7
27000Cooper Bussmann 170M65496ACS880-104-0600A-73ACS880-107-1740A-7
36000Cooper Bussmann 170M65498ACS880-104-0600A-74ACS880-107-2300A-7
45000Cooper Bussmann 170M654910ACS880-104-0600A-75ACS880-107-2860A-7
54000Cooper Bussmann 170M654912ACS880-104-0600A-76ACS880-107-3420A-7
63000Cooper Bussmann 170M654914ACS880-104-0600A-77ACS880-107-3990A-7
72000Cooper Bussmann 170M654916ACS880-104-0600A-78ACS880-107-4560A-7
81000Cooper Bussmann 170M654918ACS880-104-0600A-79ACS880-107-5130A-7
90000Cooper Bussmann 170M654920ACS880-104-0600A-710ACS880-107-5700A-7
*These are the DC fuses used for the protection of individual modules. The cubicle also contains larger main
DC fuses that are common to all modules. The size of the main DC fuses depends on the number and size of
the inverter modules. Blown fuses must be replaced using equivalent fuses.
Noise and cooling characteristics
Air flowHeat dissipation
Noise
level
Inverter unit
type
ACS880-
107-…
Total
Sine filter
(option +E206)
Inverter unitTotal
Sine filter
(option
+E206)
Inverter
unit
m
3
/h (ft
3
/min)m
3
/h (ft
3
/min)m
3
/h (ft
3
/min)kWkWkWdB(A)
U
N
= 400 V
–*24 (14)–*0.0747004A8-3
–*24 (14)–*0.0847006A0-3
–*24 (14)–*0.0947008A0-3
–*48 (28)–*0.11390011A-3
–*48 (28)–*0.14390014A-3
–*48 (28)–*0.17390018A-3
–*142 (84)–*0.20630025A-3
–*142 (84)–*0.30630035A-3
–*200 (118)–*0.35710044A-3
–*200 (118)–*0.41710050A-3
–*290 (171)–*0.50700061A-3
–*290 (171)–*0.60700078A-3
–*290 (171)–*0.74700094A-3
–*290 (171)–*0.75700100A-3
–*650 (383)–*1.1710140A-3
–*650 (383)–*1.4710170A-3
–*650 (383)–*1.8710210A-3
–*650 (383)–*2.0710250A-3
–*940 (553)–*2.5720300A-3
–*940 (553)–*3.1720350A-3
