Installation checklist of the drive
Contents of this chapter
This chapter contains a checklist of the mechanical and electrical installation of the drive.
Checklist
Examine the mechanical and electrical installation of the drive before start-up. Go through
the checklist together with another person.
WARNING!
Obey the safety instructions of the drive. If you ignore them, injury or death, or
damage to the equipment can occur.
If you are not a qualified electrical professional, do not do installation or
maintenance work.
WARNING!
Stop the drive and do the steps in section Electrical safety precautions (page 57)
before you start the work.
Make sure that …
The ambient operating conditions meet the drive ambient conditions specification, and enclosure rating
(IP code or UL enclosure type).
The supply voltage matches the nominal input voltage of the drive. See the type designation label.
The insulation resistance of the input power cable, motor cable and motor is measured according to
local regulations.
The drive cabinet is attached to the floor, and if necessary due to vibration etc, also by its top to the
wall or roof.
The drive module is fastened properly to the cabinet.
5
Installation checklist of the drive 91
