Dimensions and weights
Contents of this chapter
This chapter contains information on the dimensions and weights of ACS880-107 inverter
cubicles.
Frames R1i…R7i
￭ Frames R1i…R5i
Because of the modularity of the design, the width of the cubicle varies between 400…1000
mm according to the number and size of the modules.
The following drawing displays a 400 mm wide cubicle, but the main dimensions apart from
width are also applicable to wider cubicles. For details, refer to the dimension drawings
delivered with the unit.
Option +C128 (cooling air intake through floor of cabinet) extends the cabinet depth by 130
mm.
Weights
The table shows the estimated maximum weights of R1i…R5i cubicles.
Estimated max. weightCubicle width
Frame size
lbskgmm
530240400
R1i…R4i
685310600
880400800
10704851000
10
Dimensions and weights 157
