Connecting the motor cables
Refer to the drawings below.
WARNING!
Read the safety instructions given in Safety instructions for ACS880
multidrive cabinets and modules (3AUA0000102301 [English]). If you
ignore them, injury or death, or damage to the equipment can occur.
1.
Do the steps in section Electrical safety precautions (page 57) before you start the work.
2. Remove the shroud in front of the output busbars.
Electrical installation 73
