ABB ACS880-107 Series

Transportation
in the protective package
Storage
in the protective package
Operation
installed for stationary
use
--0…2000 m (0…6562 ft)
above sea level. For alti-
tudes over 2000 m, contact
ABB.
Installation site altitude
Output derated above 1000
m (3281 ft).
-40 to +70 °C-40 to +70 °C0 … +40 °C
(+32 … +104 °F). No con-
densation allowed.
Air temperature
(-40 to +158 °F)(-40 to +158 °F)
Output derated in the
range +40 … +50 °C
(+104 … +122 °F).
Max. 95%Max. 95%Max. 95%Relative humidity
No condensation allowed. Maximum allowed relative humidity is 60% in the presence
of corrosive gases.
IEC 60721-3-2:1997IEC 60721-3-1:1997IEC/EN 60721-3-3:2002:
Classification of environ-
mental conditions - Part 3-
3: Classification of groups
of environmental paramet-
ers and their severities -
Stationary use of weather
protected locations
Contamination
Chemical gases: Class
2C2
Solid particles: Class 2S2
Chemical gases: Class
1C2
Solid particles: Class 1S3
(packing must support this,
otherwise 1S2)
Chemical gases: Class
3C2
Solid particles: Class 3S2
(3S1 with IP20). No con-
ductive dust allowed.
2Pollution degree
IEC/EN 60721-3-2:1997IEC/EN 60721-3-1:1997IEC/EN 60721-3-3:2002Vibration
2…9 Hz: max. 3.5 mm
amplitude
10…57 Hz: max. 0.075 mm
amplitude
10…57 Hz: max. 0.075 mm
amplitude
IEC/EN 61800-5-1
IEC 60068-2-6:2007,
EN 60068-2-6:2008 Envir-
onmental testing Part 2:
Tests –Test Fc: Vibration
(sinusoidal)
9…200 Hz: 10 m/s
2
(32.8 ft/s
2
)
57…150 Hz: 1 g57…150 Hz: 1 g
Units with marine construc-
tion (option +C121): Max.
1 mm (0.04 in)
(5 … 13.2 Hz), max. 0.7 g
(13.2 … 100 Hz) sinusoidal
With packing max.
100 m/s
2
(328 ft/s
2
) 11 ms
With packing max.
100 m/s
2
(328 ft/s
2
) 11 ms
Not allowedShock
IEC 60068-2-27:2008, EN
60068-2-27:2009
Environmental testing -
Part 2-27: Tests - Test Ea
and guidance: Shock
Cooling
Fans built in inverter modules, exhauster fans in frame R1i…R5i cubicles, and
IP54 cubicles of other frame sizes. Fan in cooling air inlet of control cubicles (frame
R8i and multiples).
Method
Inlet (door): Camfil/airComp 300-50Filter material (IP54)
Outlet (roof): Camfil/airTex G150
150 Technical data
