Type designation key
The type designation contains information on the specifications and configuration of the
drive. The first digits from left express the basic drive type. The optional selections are given
thereafter, separated by plus signs, eg, +E202. Codes preceded by a minus sign (eg. -J400)
indicate the absence of the specified feature. The main selections are described below. Not
all selections are available for all types. For more information, refer to the ordering instructions
available separately on request.
DescriptionCode
Basic code
Product seriesACS880
Default configuration: Inverter unit, IEC industrial cabinet construction, plinth height 50 mm, IP22
(UL type 1), 50 Hz supply frequency, control (auxiliary) voltage 230 V AC, bottom entry and exit of
cables, European-style motor cable entries, aluminum DC busbars (up to 3200 A), tin-plated copper
DC busbars (from 3200 A up), speed-controlled module cooling fans, DC fuses, DC fuse/disconnect-
ors (frames R1iR5i only), standard wire markings, ACS880 primary control program, Safe torque
off function, coated circuit boards, USB memory stick containing complete documentation in English.
ACS880-
107
Size
Refer to the rating tablesxxxxx
Voltage range
380…415 V AC. This is indicated in the type designation label as typical input voltage level (3~ 400 V
AC)
3
380…500 V AC. This is indicated in the type designation label as typical input voltage levels
(3~ 400/480/500 V AC)
5
525…690 V AC. This is indicated in the type designation label as typical input voltage levels
(3~ 525/600/690 V AC)
7
￭ Option codes
DescriptionCode
Supply connection
50 Hz supply frequencyA012
60 Hz supply frequencyA013
Degree of protection
IP22 (UL Type 1)B053
IP42 (UL Type 1)B054
IP54 (UL Type 12)B055
Construction
Marine constructionC121
Air inlet through bottom of cabinetC128
UL Listed (evaluated to both U.S. and Canadian safety requirements)C129
Channeled air outletC130
Marine type approval. Refer to ACS880 +C132 marine type-approved cabinet-built drives supplement
(3AXD50000039629 [English]).
C132
CSA approvedC134
Plinth height 100 mmC164
Door hinges on leftC176
36 Hardware description
