DescriptionCode
Plinth height 200 mmC179
Seismic designC180
Direct-on-line module cooling fansC188
Modules in their own compartmentsC204
Filters
du/dt filteringE205
Sine output filterE206
Common mode filtering (standard with frames R6i, R7i, R8i and multiples)E208
EMC/RFI filter for 2nd environment TN (grounded) or IT (ungrounded) system, category C3E210
Switching and grounding
Service switch at inverter outputF267
Output contactorsF269
Output grounding switchF270
Output grounding terminalsF271
DC switch-disconnectorF286
DC fusesF287
DC fuse-disconnector(s)F288
Cabinet equipment
Cabinet and module heating elements (external supply)G300
Cabinet lightingG301
Control (auxiliary) voltage 115 V ACG304
Terminals for connecting external control voltage (230 V AC or 115 V AC, eg. UPS)G307
Output for motor space heater (external supply)G313
Aluminum busbarsG314
Tin-plated copper DC busbarsG315
Control (auxiliary) voltage 230 V ACG320
Halogen-free wiring and materialsG330
Additional wire markings
G338
G339
G340
G341
G342
Corrosion indicatorG343
Auxiliary voltage transformerG344
Light-duty aluminum (see also the hardware manual of the supply unit)G412
Common mode filter temperature monitoringG453
Cabling
Supply cabling direction downH350
Supply cabling direction upH351
Motor cabling direction downH352
Motor cabling direction upH353
Cable conduit entry (US/UK)H358
Hardware description 37
