Estimated max. weightCubicle width
Frame size
lbskgmm
440200300
R5i 705320*500
615280**500
*Without option +C204, **with option +C204.
￭ Frames R6i and R7i
Each frame R6i and R7i inverter unit is housed in a 400 mm wide cubicle such as the one
pictured below. The approximate weight of the cubicle is 250 kg (550 lbs). For details, refer
to the dimension drawings delivered with the unit.
Options +H353 (motor cabling through roof of cabinet) and +C128 (cooling air intake through
floor of cabinet) extend the cabinet depth by 130 mm.
158 Dimensions and weights
