8. Attach the module extraction/installation ramp (included) to the base of the cabinet so
that the tabs on the mounting bracket enter the slots on the ramp.
WARNING!
Check the markings on the ramp to make sure that it is suitable for the plinth
height.
9. Remove the two retaining screws at the bottom front of the module.
WARNING!
Before you proceed, make sure the cabinet is level, or chock the wheels of
the module.
10. Remove the two retaining screws at the top front of the module.
11. Pull the module carefully out along the ramp. While pulling on the handle with your right
hand, keep a constant pressure with one foot on the base of the module to prevent the
module from falling on its back.
12. Move the module into a safe location outside the immediate work area and make sure
it cannot topple over. Chock the wheels of the module if the floor is not completely level.
13. Repeat the procedure for the other inverter modules.
68 Electrical installation
