Fault tracing 495
AAA6 FSO SLS3 hit FSO module detected an
SLS3 speed trip limit
violation.
Investigate the reason for trip from
the application point of view. If
application is OK, then make sure
that SLS is configured properly.
Make sure that SLS trip limits are
defined properly.
Check that mute time values are
defined properly (FSOGEN.31 or
SLSx.37 if enabled, and
FSOGEN.33).
2) 6)
AAA7 FSO SLS4 hit FSO module detected an
SLS4 speed trip limit
violation.
Investigate the reason for trip from
the application point of view. If
application is OK, then make sure
that SLS is configured properly.
Make sure that SLS trip limits are
defined properly.
Check that mute time values are
defined properly (FSOGEN.31 or
SLSx.47 if enabled, and
FSOGEN.33).
2) 6)
AAA8 FSO SMS hit FSO module detected an
SMS speed trip limit
violation.
Investigate the reason for trip from
the application point of view. If
application is OK, then make sure
that SMS is configured properly.
Make sure that SMS trip limits are
defined properly.
Check that mute time values are
defined properly (FSOGEN.31 or
SMS.17 if enabled).
2) 6)
AAA9 FSO SAR0 hit FSO module detected an
SAR0 limit violation.
Make sure that the drive can
decelerate the load using the ramp
time (200.102 SAR0 ramp time to
zero).
2)
AAAA FSO SAR1 hit FSO module detected an
SAR1 limit violation.
Make sure that the drive can
decelerate the load using the ramp
time (200.112 SAR1 ramp time to
zero).
2)
AAB0 FSO SDI positive
hit
SDI positive exceeded the
tolerance limit to the
forbidden direction.
Make sure that SDI tolerance values
are defined properly.
Check limits of the drive.For example,
see the usage of DC hold from the
drive firmware manual.
2)
Code
(hex)
Name Cause What to do
