Abov MC96F6432S Series User Manual

95
MC96F6432S
ABOV Semiconductor Co., Ltd.
EIFLAG0 (External Interrupt Flag0 Register): C0H
7
6
5
4
3
2
1
0
FLAG7
FLAG6
FLAG5
FLAG4
FLAG3
FLAG2
FLAG1
FLAG0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value :00H
EIFLAG0[7:0]
When an External Interrupt 0-7 is occurred, the flag becomes ‘1’.The flag is cleared
only by writing ‘0’ to the bit. So, the flag should be cleared by software.
0
External Interrupt0 ~ 7 not occurred
1
External Interrupt0 ~ 7 occurred
NOTE)
1. Do not use the “direct bit test and branch” instruction for input port. More detail information is at chapter
17.2 Instructions on how to use the input port.
Example) Avoid direct input port bit test and branch condition as below
if(FLAG0) → if(EIFLAG0 & 0x01)
EIPOL0H (External Interrupt Polarity 0High Register): A5H
7
6
5
4
3
2
1
0
POL7
POL6
POL5
POL4
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
EIPOL0H[7:0]
External interrupt (EINT7, EINT6, EINT5, EINT4) polarity selection
POLn[1:0]
Description
0
0
No interrupt at any edge
0
1
Interrupt on rising edge
1
0
Interrupt on falling edge
1
1
Interrupt on both of rising and falling edge
Where n =4, 5, 6 and 7
EIPOL0L (External Interrupt Polarity 0Low Register): A4H
7
6
5
4
3
2
1
0
POL3
POL2
POL1
POL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
EIPOL0L[7:0]
External interrupt (EINT0, EINT1, EINT2, EINT3) polarity selection
POLn[1:0]
Description
0
0
No interrupt at any edge
0
1
Interrupt on rising edge
1
0
Interrupt on falling edge
1
1
Interrupt on both of rising and falling edge
Where n =0, 1, 2 and 3
