18 UK
The adhesive on the antenna bonds immediately. You cannot correct the
position once the antenna is fixed in place.
9.2.3 PSTN module
The PSTN module is a plug-in board for the device. It allows connection to a
wired telephone network.
The PSTN module is connected to the mainboard at the factory.
Caution!
Disconnect the device from the power before you remove (detach) the PSTN
module and reattach it.
Remove the PSTN module from the mainboard.
Place the plastic spacer as indicated in the picture. It is usually
preassembled, however.
Remove the protective foil of the tape strip only after all wiring and testing is
complete.
