Specifications
Maximum number of
simultaneous effects
6 effects
User patch memories 240
Sampling frequency 88.2 kHz
A/D conversion 24-bit 128× oversampling
D/A conversion 24-bit 128× oversampling
Signal processing 32-bit
Frequency response 20 Hz – 20 kHz (+0.5 dB/−0.5 dB) (10kΩ load)
Display 4.3" TFT color LCD (480×272)
Inputs INPUT 1/2 Standard mono phone jacks
Rated input level: −20 dBu
Input impedance (line): 1 or 10 MΩ (switchable)
RETURN Standard mono phone jack
Rated input level: −20 dBu
Input impedance (line): 1 MΩ
AUX IN Stereo mini jack
Rated input level: −10 dBu
Input impedance (line): 10 kΩ
Outputs AMP/LINE [PHONES] Standard stereo phone jack
Maximum output level: Line
＋
11.4 dBu (when 10 kΩ or more
output impedance)/Phones 24 mW
＋
24 mW (32 Ω load)
BALANCED OUTPUT XLR jack
Impedance: 100 Ω (HOT-GND, COLD-GND)/200 Ω (HOT-COLD)
GND LIFT (switchable)
SEND Standard mono phone jack
Maximum output level:
＋
11.4 dBu (when 10 kΩ or more
output impedance)
AMP/LINE [PHONES] –96.0 dBuNoise floor (residual noise)
BALANCED OUTPUT –100.0 dBu
SEND –99.0 dBu
Control input FP02M input
Power AC adapter (9V DC 500mA, center negative) (ZOOM AD-16)
128
