ACUTRONIC fabian +nCPAP evolution User Manual

19 Technical specifications 125
fabian +nCPAP evolution | SW V5.1.x
Ref: 122003.EN / Date : 26Jan2021
19.8 Data storage
Alarms
Maximum: 1.000 messages.
Log
Maximum: 10 Log Files.
Log is stored during power failure.
When Log capacity is reached, index is shifted and oldest log file deleted.
Trend
Maximum: 5 days.
Storage: every 30 seconds.
19.9 Applied parts
Applied parts for the device are as follows:
• Flow Sensor
• Nebulizer
• SpO
2
module (type BF)
• Tube set (type B)
19.10 Internal device checks
The following internal device checks are performed on Startup:
• COM :
Communication between GUI and Conductor PIC.
• DIO :
Communication between GUI and Digital I/O.
• I
2
C :
Communication between GUI to AccuPIC, NVRAM and Multiplexer.
• PIF :
Communication between GUI and Parallel Interface
• Relias :
Relay Check from the SPI
• SPI :
Communication between GUI and Monitor PIC.
• SPICks :
SPI Checksum
• Voltage :
Voltage Error Check from the SPI
19.11 Gas blender function
The Air / Oxygen Blender provides a Gas blend with adjustable proportions of Oxygen and Air.
Gas from the central gas supply enters the device through the gas input connections.
Blending of the gases occurs through two proportional valves.
The Proportional Valves, which also act as return valves, prevent the return flow of a gas into the
supply line of the other gas.
An Oxygen sensor measures the Inspiratory Oxygen Concentration.
