ACUTRONIC fabian +nCPAP evolution - SIMV

11 Ventilation modes 79
fabian +nCPAP evolution | SW V5.1.x
Ref: 122003.EN / Date : 26Jan2021
11.3 SIMV
Breaths triggered by the patient will be displayed in green (default settings).
Ventilation with specified pattern and
frequency synchronous to the patient’s
independent breathing.
The patient can spontaneously breathe
in between breaths but receives no
pressure support.
For weaning from ventilation.
If Apnea is detected, ventilation will
commence with the specified TI and TE
frequency.
The synchronization window for the
next mechanical breath is maximum ½
Te.
See Section 10: “Ventilation parameters”
See Section 11.9: “Ventilation Additives”
