ACUTRONIC fabian +nCPAP evolution User Manual

48 6 Configurations menu
fabian +nCPAP evolution | SW V5.1.x
Ref: 122003.EN / Date : 26Jan2021
6.1.3 SpO
2
module
Refer to section “12.3: SpO2 module”
6.2 Body weight setting
You can set the patient’s body weight in Calibration menu. This setting is
used to calculate and display the VTe BW [mL/kg] Numeric measurement
in IPPV and SIPPV modes.
6.3 Display
Figure 6-5: Display screen settings
1. Lock Touch screen. The screen will automatically be unlocked if an alarm is triggered or the
Rotary Push knob is pressed.
2. Automatic lock activated / deactivated. Touchscreen automatically locks after a set time.
3. Display Graphs and trends as filled or regular lines.
4. Autoscale ON / OFF
1
2
3
4
