ACUTRONIC fabian +nCPAP evolution User Manual

50 6 Configurations menu
fabian +nCPAP evolution | SW V5.1.x
Ref: 122003.EN / Date : 26Jan2021
6.3.2 Trend / graph display
Graphs display (1)
Graphs display:
• filled
• not filled
Figure 6-7: Filled Graph
Figure 6-8: Not Filled Graph
Auto-scaling trends (2):
• ON
• OFF
Trend patterns are automatically scaled.
Scaling can be performed manually with
the (− / ) keys on the keypad for the
timeline.
For Wave height, use the Manual inspiration and
O
2
Flush keys on the keypad
1
2
