ACUTRONIC fabian +nCPAP evolution User Manual

4 System functions and displays 21
fabian +nCPAP evolution | SW V5.1.x
Ref: 122003.EN / Date : 26Jan2021
If the device shuts down with warning LED blinking simultaneously with
battery LED, this represents a device fault. Then follow these steps:
Immediately take the device out of service and provide an alternative
means of ventilation to the patient;
Report the incident to your local distributor
DO NOT use the device until it has been checked by suitably trained and
qualified personnel.
4.3 Ventilation menu
4.3.1 Operation – General
Push buttons and their statuses are
indicated by various colors:
Light Blue: Push button
Dark Blue: focused push button
Yellow: (in Functions field):
parameter value set
automatically
Green: selected push button, if
the push button features a
parameter for setting a value it
can now be changed.
Orange: parameter is
automatically adjusted by the
device.
The value set by the user indicates the
maximum value and will NOT be
exceeded.
Depending on the Ventilation mode,
The Information bar (1) indicates
current information.
Using the push button (2) you may
also switch between the pressure-,
volume- and flow wave (3).
the Ventilation menu indicates the
configuration parameters (4) and
measurements (5) relevant in the
mode.
The Ventilation mode may be
changed in the menu.
Figure 4-8: Operation screen
1
2
3
4
5
