4 System functions and displays 25
fabian +nCPAP evolution | SW V5.1.x
Ref: 122003.EN / Date : 26Jan2021
4.4 Graphics menu
The Graphics menu can be accessed from the Waves button on the Keypad.
The Graphics menu
The following graphics are available in
the Graphics menu:
Waves
Figure 4-12: Waves
Loops
Figure 4-13: Loops
Trends
Figure 4-14: Trends
