60 7 Alarms
fabian +nCPAP evolution | SW V5.1.x
Ref: 122003.EN / Date : 26Jan2021
7.1.2 Configurable alarms
Following alarm limits are displayed and can be configured in the Alarm
Limits menu.
• High SpO
2
alarm :
2 to 99%, off
• Low SpO
2
alarm :
off, 1 to 98%
• High Pulse Rate alarm :
35 to 235 bpm, off
• Low Pulse Rate alarm :
off, 30 to 230 bpm
• Low Perfusion Index alarm :
off, 0.03 to 19%
• Low SIQ Alarm :
off, 5 to 100%.
7.2 Alarm log
Switch to alarm limit menu
Press the button underneath
Show Log to access the Alarm
Overview.
The Alarm List is sorted in
chronological order.
The parameters shown are:
• Time
• Message
• Priority (highlighted. See
section: “7.4.1:
Alarms table”)
Press the button underneath
Hide Log to return to the Alarm
Limits menu.
Figure 7-3: Alarm Log screen
Switching OFF the device will erase the Alarm Log displayed in clinical use. The
Alarm Log files capable of export from the submenu (Tools) will not be deleted.
In case alarm list or alarm log files reach their limit (100 / ca. 70000 entries respectively),
the oldest entries are deleted first.
7.3 Nurse call relay
The delay from the nurse call relay is < 1 second.
