8.2.18 Fault functions
 31.01 External event 1 source
 0: Active (Active high signal)
 1: Inactive (Active low signal) ----- Initial value
 2: DI1
 3: DI2
 4: DI3
 5: DI4
 6: DI5
 7: DI6
 8: DI7
 9: DI8
Define the source of external event 1
 31.02 External event 2 source
See the parameter '31.01' (External event 1 source)
 31.03 External event 3 source
See the parameter '31.01' (External event 1 source)
 31.04 External event 4 source
See the parameter '31.01' (External event 1 source)
 31.05 External event 5 source
See the parameter '31.01' (External event 1 source)
 31.06 Fault(Trip) reset selection
 0: Not selected
 1: Selected
 2: DI1
 3: DI2
 4: DI3
 5: DI4
 6: DI5
 7: DI6 ----- Initial value
 8: DI7
 9: DI8
Selects the source of an external fault reset signal
The signal resets the drive after a fault trip if the cause of the fault no longer exists.
