8.1.26 Fieldbus (option)
No.
Name
Change during
operation
Range
Default
Page
51.01
Fieldbus option type
X
0: Modbus
1: Profibus-DP
2: Device-Net
3: Ethernet series
4: Reserved
4
164
51.02
Fieldbus station number
X
32: Ethernet series
63: Device-Net
125: Profibus-DP
125
164
51.03
Fieldbus byte swap
X
0: Normal
1: Swap
1
164
51.08
Fieldbus input data 1
X
0x0000 to 0xFFFF
0x0603
164
51.09
Fieldbus input data 2
X
0x0000 to 0xFFFF
0x0001
164
51.10
Fieldbus input data 3
X
0x0000 to 0xFFFF
0x0202
164
51.11
Fieldbus input data 4
X
0x0000 to 0xFFFF
0x0203
164
51.12
Fieldbus input data 5
X
0x0000 to 0xFFFF
0x0201
164
51.13
Fieldbus input data 6
X
0x0000 to 0xFFFF
0x0101
164
51.14
Fieldbus input data 7
X
0x0000 to 0xFFFF
0x0102
164
51.15
Fieldbus input data 8
X
0x0000 to 0xFFFF
0x010C
164
51.16
Fieldbus input data 9
X
0x0000 to 0xFFFF
0x010d
164
51.17
Fieldbus input data 10
X
0x0000 to 0xFFFF
0x0111
164
51.18
Fieldbus input data 11
X
0x0000 to 0xFFFF
0x0115
164
51.19
Fieldbus input data 12
X
0x0000 to 0xFFFF
0x0000
164
51.20
Fieldbus output data 1
X
0x0000 to 0xFFFF
0x0202
164
51.21
Fieldbus output data 2
X
0x0000 to 0xFFFF
0x0203
164
51.22
Fieldbus output data 3
X
0x0000 to 0xFFFF
0x0201
164
51.23
Fieldbus output data 4
X
0x0000 to 0xFFFF
0x0002
164
51.24
Fieldbus output data 5
X
0x0000 to 0xFFFF
0x0000
164
51.25
Fieldbus output data 6
X
0x0000 to 0xFFFF
0x0000
164
51.26
Fieldbus output data 7
X
0x0000 to 0xFFFF
0x0000
164
51.27
Fieldbus output data 8
X
0x0000 to 0xFFFF
0x0000
164
51.28
Fieldbus output data 9
X
0x0000 to 0xFFFF
0x0000
164
51.29
Fieldbus output data 10
X
0x0000 to 0xFFFF
0x0000
164
51.30
Fieldbus output data 11
X
0x0000 to 0xFFFF
0x0000
164
51.31
Fieldbus output data 12
X
0x0000 to 0xFFFF
0x0000
164
51.32
Fieldbus status
X
0x0000 to 0xFFFF
-
164
51.33
Fieldbus version
X
0x0000 to 0xFFFF
-
164
