8.2.6 Standard DI, DO
 10.01 DI status
Range: 0x00 ~ 0xFF
It displays the status of digital input
Example Data: 0000000000001111
Meaning: DI8~DI5 OFF, DI4~DI1 ON
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
It displays when extension I/O card is connected
DI8
DI7
DI6
DI5
DI4
DI3
DI2
DI1
 10.02 DI Delayed status
Range: 0x00 ~ 0xFF
It displays the status of digital input that delayed
Example Data: 0000000011110000
Meaning: DI8~DI5 ON, DI4~DI1 OFF
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
It displays when extension I/O card is connected
DI8
DI7
DI6
DI5
DI4
DI3
DI2
DI1
 10.03 DI Forced selection
Range: 0x00 ~ 0xFF
Initial value: 0x00
The statuses of the digital input can be overridden for example testing purposes
A bit in parameter '10.04' (DI forced data) is provided for each digital input and its value is
applied whenever the corresponding bit in this parameter is 1
 10.04 DI Forced data
Range: 0x00 ~ 0xFF
Initial value: 0x00
Allows the data value of a forced digital input to be changed from 0 to 1
It is only possible to forced an input that has been selected in parameter
'10.03' (DI forced selection)
