Adtech iMASTER – A1 Series - DBR Duty Cycle; Monitoring;Scaling; Droop; Modbus)

A1-User’s Manual
７５
8.1.22 DBR Duty Cycle
No.
Name
Change during
operation
Range
Default
Page
41.01
DBR Mode
X
0: DBR disabled
1: Only during VFD running
2: Always
1
152
41.02
DBR Duty cycle
X
0.0~50.0%
10.0
152
8.1.23 Monitoring/Scaling
No.
Name
Change during
operation
Range
Default
Page
42.01
Frequency scaling
X
0.00 to 400.0 [Hz]
60.00 Hz
153
42.02
Rpm display scale factor
O
1 to 9999
100
153
42.10
Flux braking operating
frequency
X
0 to 10.00 [Hz]
5.00 Hz
153
8.1.24 Droop
No.
Name
Change during
operation
Range
Default
Page
43.01
Droop type
O
0: No droop control
1: Open loop
2: F/B (0~10V)
3: F/B (4~20mA)
0
154
43.02
Droop start frequency
O
0.00 to 400.0 [Hz]
0.00 Hz
154
43.04
Droop gain
O
0.00 to 50.00
5.00
155
43.05
Droop start torque
O
0.0 to 100.0 [%]
0.0 %
155
43.06
Droop ramp time
O
1.0 to 100.0 [Sec]
20.0 Sec
155
8.1.25 RS-485 (Modbus)
No.
Name
Change during
operation
Range
Default
Page
50.01
Modbus node ID
X
1 to 32
1
157
50.02
Modbus baud rate
X
1. 2,400 [bps]
2. 4,800 [bps]
3. 9,600 [bps]
4. 19,200 [bps]
3
157
